Cisco Intel Xeon Gold 6338 processor 2 GHz 48 MB Tray
Cisco Intel Xeon Gold 6338 processor 2 GHz 48 MB Tray

Cisco Intel Xeon Gold 6338 processor 2 GHz 48 MB Tray

Cisco · MPN: UCS-CPU-I6338
£5,708.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,902.99 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview
  • Intel® Xeon® 6338 2 GHz
  • 48 MB LGA 4189
  • Processor cores: 32 10 nm 64-bit 205 W
  • Maximum internal memory supported by processor: 6.14 TB DDR4-SDRAM
  • Tray

Specifications

Processor

Processor ARK ID212285
Processor codenameIce Lake
Thermal Design Power (TDP)205 W
Processor cache48 MB
Low priority core frequency1.8 GHz
Low priority cores20
High priority core frequency2.2 GHz
High priority cores12
Processor boost frequency3.2 GHz
Processor operating modes64-bit
System bus rate11.2 GT/s
Processor threads64
Component forServer/workstation
Cooler includedNo
Processor lithography10 nm
Processor socketLGA 4189
Processor cores32
Processor base frequency2 GHz
Processor model6338
Processor generation3rd Generation Intel® Xeon® Scalable
Processor familyIntel® Xeon®
Processor manufacturerIntel

Memory

ECCYes
Memory channelsOcta-channel
Memory clock speeds supported by processor3200 MHz
Memory types supported by processorDDR4-SDRAM
Maximum internal memory supported by processor6.14 TB
Show all 72 specificationsShow fewer specifications

Graphics

Discrete graphics card modelNot available
On-board graphics card modelNot available
On-board graphics cardNo
Discrete graphics cardNo

Features

Commodity Classification Automated Tracking System (CCATS)G178966
Export Control Classification Number (ECCN)5A992CN3
Scalability2S
Embedded options availableNo
Supported instruction setsSSE4.2, AVX, AVX 2.0, AVX-512
PCI Express slots version4.0
Maximum number of PCI Express lanes64
Market segmentServer
Execute Disable BitYes

Processor special features

Intel VT-x with Extended Page Tables (EPT)Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
AVX-512 Fused Multiply-Add (FMA) units2
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Resource Director Technology (Intel® RDT)Yes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Optane™ DC Persistent Memory SupportedYes
Intel® Run Sure TechnologyYes
Intel® Optane™ Memory ReadyYes
Intel® Crypto AccelerationYes
Intel® Platform Firmware Resilience SupportYes
Maximum Enclave Size Support for Intel® SGX64 GB
Intel® Total Memory EncryptionYes
Intel® Transactional Synchronization ExtensionsYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel® Speed Shift TechnologyYes

Operational conditions

Tcase81 °C

Technical details

Servicing statusBaseline Servicing
Launch dateQ2'21
StatusLaunched
Memory speed (max)3200 MHz
Number of UPI links3
Supported memory typesDDR4-SDRAM

Weight & dimensions

Processor package size77.5 x 56.5 mm

Other features

Maximum internal memory6 TB
