Cisco Intel Xeon Gold 5420+ processor 2 GHz 52.2 MB
Cisco Intel Xeon Gold 5420+ processor 2 GHz 52.2 MB

Cisco Intel Xeon Gold 5420+ processor 2 GHz 52.2 MB

Cisco · MPN: UCSX-CPU-I5420+
£4,555.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,518.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview
  • Intel® Xeon® Gold 5420+ 2 GHz
  • 52.2 MB LGA 4677 (Socket E)
  • Processor cores: 28 64-bit 205 W
  • Maximum internal memory supported by processor: 6 TB DDR4-SDRAM

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.

Specifications

Processor

Processor codenameSapphire Rapids
SteppingS3
Thermal Design Power (TDP)205 W
Processor cache52.2 MB
Low priority cores20
High priority core frequency2.2 GHz
High priority cores8
Processor boost frequency4.1 GHz
Processor operating modes64-bit
System bus rate16 GT/s
Processor threads56
Processor seriesIntel Xeon Gold 5000 Series
Processor socketLGA 4677 (Socket E)
Processor cores28
Processor base frequency2 GHz
Processor model5420+
Processor generationIntel Xeon Scalable 4th Gen
Processor familyIntel® Xeon® Gold
Processor manufacturerIntel

Memory

ECCYes
Memory channelsOcta-channel
Memory types supported by processorDDR4-SDRAM
Maximum internal memory supported by processor6 TB
Show all 65 specificationsShow fewer specifications

Graphics

Discrete graphics card modelNot available
On-board graphics card modelNot available
On-board graphics cardNo
Discrete graphics cardNo

Features

Scalability2S
Embedded options availableYes
Supported instruction setsAMX, AVX, AVX 2.0, AVX-512, SSE4.2
PCI Express slots version5.0
Maximum number of PCI Express lanes80
Use conditionsServer/Enterprise
Market segmentServer
Execute Disable BitYes

Processor special features

Intel® Advanced Matrix Extensions (AMX)Yes
Intel® On Demand Feature ActivationYes
Intel® QuickAssist Software AccelerationYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
AVX-512 Fused Multiply-Add (FMA) units2
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Resource Director Technology (Intel® RDT)Yes
Mode-based Execute Control (MBE)Yes
Intel® Optane™ DC Persistent Memory SupportedYes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)Yes
Intel® OS GuardYes
Intel® Run Sure TechnologyYes
Intel® Boot GuardYes
Intel® Crypto AccelerationYes
Intel® Platform Firmware Resilience SupportYes
Maximum Enclave Size Support for Intel® SGX128 GB
Intel® Control-flow Enforcement Technology (CET)Yes
Intel® Total Memory EncryptionYes
Intel® Transactional Synchronization ExtensionsYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel® Speed Shift TechnologyYes

Operational conditions

Tcase84 °C
DTS Max97 °C
