Cisco Intel Xeon Gold 5318Y processor 2.1 GHz 36 MB Tray
Cisco Intel Xeon Gold 5318Y processor 2.1 GHz 36 MB Tray

Cisco Intel Xeon Gold 5318Y processor 2.1 GHz 36 MB Tray

Cisco · MPN: UCS-CPU-I5318Y
£2,842.99
inc. VAT
Spread the cost with Klarna, PayPal, Float or SnapFrom 3 interest-free payments of £947.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview
  • Intel® Xeon® Gold 5318Y 2.1 GHz
  • 36 MB LGA 4189
  • Processor cores: 24 10 nm 64-bit 165 W
  • Maximum internal memory supported by processor: 6 TB DDR4-SDRAM
  • Tray

Specifications

Processor

Processor ARK ID215271
Processor codenameIce Lake
Thermal Design Power (TDP)165 W
Processor cache36 MB
Low priority core frequency1.8 GHz
Low priority cores16
High priority core frequency2.3 GHz
High priority cores8
Processor boost frequency3.4 GHz
Processor operating modes64-bit
System bus rate11.2 GT/s
Processor threads48
Processor seriesIntel Xeon Gold 5000 Series
Component forServer/workstation
Cooler includedNo
Processor lithography10 nm
Processor socketLGA 4189
Processor cores24
Processor base frequency2.1 GHz
Processor model5318Y
Processor generation3rd Generation Intel® Xeon® Scalable
Processor familyIntel® Xeon® Gold
Processor manufacturerIntel

Memory

ECCYes
Memory channelsOcta-channel
Memory clock speeds supported by processor2933 MHz
Memory types supported by processorDDR4-SDRAM
Maximum internal memory supported by processor6 TB
Show all 74 specificationsShow fewer specifications

Graphics

Discrete graphics card modelNot available
On-board graphics card modelNot available
On-board graphics cardNo
Discrete graphics cardNo

Features

Commodity Classification Automated Tracking System (CCATS)G178966
Export Control Classification Number (ECCN)5A992CN3
Scalability2S
Embedded options availableYes
Supported instruction setsSSE4.2, AVX, AVX 2.0, AVX-512
PCI Express slots version4.0
Maximum number of PCI Express lanes64
Market segmentServer
Execute Disable BitYes

Processor special features

Intel VT-x with Extended Page Tables (EPT)Yes
Intel Software Guard Extensions (Intel SGX)Yes
Intel 64Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
AVX-512 Fused Multiply-Add (FMA) units2
Intel® Deep Learning Boost (Intel® DL Boost) on CPUYes
Intel® Resource Director Technology (Intel® RDT)Yes
Intel® Volume Management Device (VMD)Yes
Mode-based Execute Control (MBE)Yes
Intel® Optane™ DC Persistent Memory SupportedYes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)Yes
Intel® Run Sure TechnologyYes
Intel® Crypto AccelerationYes
Intel® Platform Firmware Resilience SupportYes
Maximum Enclave Size Support for Intel® SGX64 GB
Intel® Total Memory EncryptionYes
Intel® Transactional Synchronization ExtensionsYes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel Trusted Execution TechnologyYes
Intel® Speed Shift TechnologyYes

Operational conditions

Tcase87 °C

Technical details

Servicing statusBaseline Servicing
Launch dateQ2'21
StatusLaunched
Memory speed (max)2933 MHz
Number of UPI links3
Target marketCloud Computing
Supported memory typesDDR4-SDRAM

Weight & dimensions

Processor package size77.5 x 56.5 mm

Other features

Maximum internal memory6 TB
