Cisco Intel Xeon 6527P processor 3 GHz 144 MB
£8,210.99
Couldn't load pickup availability
- Intel Xeon 6 6527P 3 GHz
- 144 MB LGA 4710
- Processor cores: 24 3 nm 64-bit 255 W
- Maximum internal memory supported by processor: 4 TB DDR5-SDRAM
The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.
| Processor | |
|---|---|
| Thermal Design Power (TDP) | 255 W |
| Processor cache | 144 MB |
| Low priority core frequency | 0.8 GHz |
| Low priority cores | 16 |
| High priority cores | 8 |
| Processor operating modes | 64-bit |
| Intel® UPI Speed | 24 GT/s |
| Processor threads | 48 |
| Processor lithography | 3 nm |
| Processor socket | LGA 4710 |
| Processor cores | 24 |
| Processor base frequency | 3 GHz |
| Processor model | 6527P |
| Processor family | Intel Xeon 6 |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory clock speeds supported by processor | 6400 MHz |
| Memory types supported by processor | DDR5-SDRAM |
| Maximum internal memory supported by processor | 4 TB |
| Graphics | |
|---|---|
| Discrete graphics card model | Not available |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card | No |
| Features | |
|---|---|
| Scalability | 2S |
| Embedded options available | No |
| Supported instruction sets | AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
| PCI Express slots version | 5.0 |
| Maximum number of PCI Express lanes | 88 |
| Market segment | Server |
| Execute Disable Bit | Yes |
| Processor special features | |
|---|---|
| Intel® Speed Select Technology – Turbo Frequency | Yes |
| Intel® Speed Select Technology – Core Power | Yes |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® In-memory Analytics Accelerator (IAA) | 4 |
| Intel® Data Streaming Accelerator (DSA) | 4 |
| Intel® Dynamic Load Balancer (DLB) | 4 |
| Intel® QuickAssist Technology (QAT) | 4 |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | Yes |
| Intel® Secure Key | Yes |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Boot Guard | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Trust Domain Extensions (Intel® TDX) | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Operational conditions | |
|---|---|
| Tcase | 79 °C |
| DTS Max | 102 °C |
| Technical details | |
|---|---|
| Number of UPI links | 4 |
| Package carrier | E2B |
