Cisco IEM-3000-8TM, Refurbished network switch module
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £155.33 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- 10,100 Mbit/s Full duplex
- Data transfer rate: 1 Gbit/s
- Quality of Service (QoS) support
- 2.8 W
The Cisco® Industrial Ethernet 3000 Series (IE 3000 Series) is a family of Layer 2 and Layer 3 switches that bring Cisco’s leadership in switching to Industrial Ethernet applications with Innovative features, robust security, and superior ease of use. The Cisco IE 3000 Series features:
- Industrial design and compliance
- Tools for easy deployment, management, and replacement
- Network security based on open standards
- Integration of IT and industrial automation networks
The Cisco IE 3000 Series is an ideal product for Industrial Ethernet applications, including factory automation, energy and process control, and intelligent transportation systems (ITSs).
The Cisco IE 3000 offers:
- Design for Industrial Ethernet applications, including extended environmental, shock/vibration, and surge ratings; a complete set of power input options; convection cooling; and DIN-rail or 19” rack mounting
- Support for Power over Ethernet (PoE) up to 15.4W per port
- Support for Power over Ethernet Plus (PoE+) for the PoE+ capable devices up to 30W per port
- Easy setup and management using the Cisco Device Manager web interface and supporting tools, including Cisco Network Assistant (CNA) and Cisco Prime LMS 4.2
- Easy switch replacement using removable memory, allowing the user to replace a switch without having to reconfigure
- High availability, guaranteed determinism, and reliable security using Cisco IOS®Software
- Recommended software configurations for industrial applications that can be applied at the touch of a button
- Compliance to a wide range of Industrial Ethernet specifications covering industrial automation, ITS, substation, railway, and other markets
- Support for IEEE1588v2, a precision timing protocol with nanosecond-level precision for high-performance applications
- Improved ring resiliency with the support of Resilient Ethernet Protocol (REP)
- Transparent IT integration with the support of Layer 3 routing protocols (IP Services)
- PROFINET v2 certification, with PROFINET conformance class B compliance
- ABB Industrial IT certification
Cisco IEM-3000-8TM=:
Expansion copper Module for Cisco IE-3000-4TC, IE-3000-8TC, IE-3000-4TC-E, and IE-3000-8TC-E switches, eight 10/100 TX ports
Specifications
Network
| Jumbo frames support | Yes |
|---|---|
| Full duplex | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
Data transmission
| Data transfer rate | 1 Gbit/s |
|---|
Show all 17 specificationsShow fewer specifications
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 8 |
|---|
Performance
| Compatibility | Cisco IE-3000-4TC, IE-3000-8TC |
|---|---|
| Mean time between failures (MTBF) | 926999 h |
| Quality of Service (QoS) support | Yes |
Power
| Power consumption (typical) | 2.8 W |
|---|
Operational conditions
| Operating temperature (T-T) | -40 - 75 °C |
|---|---|
| Storage temperature (T-T) | -25 - 85 °C |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 10 - 95% |
Weight & dimensions
| Weight | 1 kg |
|---|---|
| Height | 147 mm |
| Depth | 112 mm |
| Width | 89 mm |
