Cisco 6148 processor 2.4 GHz 27.5 MB L3
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,764.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Intel® Xeon® Gold 6148 2.4 GHz
- 27.5 MB L3 LGA 3647 (Socket P)
- Processor cores: 20 14 nm 64-bit 150 W
- Maximum internal memory supported by processor: 768 GB DDR4-SDRAM
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel® Trusted Execution Technology for safer computing is a versatile set of hardware extensions to Intel® processors and chipsets that enhance the digital office platform with security capabilities such as measured launch and protected execution. It enables an environment where applications can run within their own space, protected from all other software on the system.
Enhanced Intel SpeedStep® Technology is an advanced means of enabling high performance while meeting the power-conservation needs of mobile systems. Conventional Intel SpeedStep® Technology switches both voltage and frequency in tandem between high and low levels in response to processor load. Enhanced Intel SpeedStep® Technology builds upon that architecture using design strategies such as Separation between Voltage and Frequency Changes, and Clock Partitioning and Recovery.
Specifications
Processor
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Xeon® Gold |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 6148 |
| Processor base frequency | 2.4 GHz |
| Processor cores | 20 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Cooler included | No |
| Component for | Server/workstation |
| Processor threads | 40 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.7 GHz |
| Processor cache | 27.5 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 150 W |
| Stepping | H0 |
| Processor codename | Skylake |
| Processor code | SR3B6 |
| Processor ARK ID | 120489 |
Memory
| Maximum internal memory supported by processor | 768 GB |
|---|---|
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Show all 78 specificationsShow fewer specifications
Graphics
| Discrete graphics card | No |
|---|---|
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Execute Disable Bit | Yes |
|---|---|
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | SSE4.2, AVX, AVX 2.0, AVX-512 |
| PCI Express CEM revision | 3.0 |
| Embedded options available | No |
| Scalability | S4S |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
Processor special features
| Enhanced Intel SpeedStep Technology | Yes |
|---|---|
| Intel® Speed Shift Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Conflict-Free processor | Yes |
| Intel TSX-NI version | 1.00 |
| Intel® vPro™ Platform Eligibility | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel TSX-NI | Yes |
| Intel® Run Sure Technology | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel 64 | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
Operational conditions
| Tcase | 86 °C |
|---|
Technical details
| Processor cache | 28160 KB |
|---|---|
| Product type | Processor |
| Supported memory types | DDR4-SDRAM |
| Intel® Speed Shift Technology version | 1.00 |
| Product family | Intel Xeon Processors |
| Last change | 63903513 |
| Processor brand name | Intel Xeon Gold Intel Xeon Gold Processor |
| Maximum memory | 768 GB |
| Mode-based Execute Control (MBE) version | 1.00 |
| Intel® Volume Management Device (VMD) version | 1.00 |
| Intel® Run Sure Technology version | 1.00 |
| Number of UPI links | 3 |
| Memory speed (max) | 2666 MHz |
| Status | Launched |
| Launch date | Q3'17 |
Weight & dimensions
| Processor package size | 76mm x 56.5mm |
|---|
Other features
| Maximum internal memory | 786432 MB |
|---|
