Cables Direct NLKVMHDMI-22A KVM switch Black
£60.99
Couldn't load pickup availability
- One USB console controls up to 4 HDMI interface computers, depending on model
- Switch Mode: a. Wire remote push button b. Keyboard Hot-key switch c. Mouse switch d. Button switch on front panel
- Supports 4096 x 2160p @ 60Hz
- OS Support: Windows 10, 7 and Mac OS
- Plug and Play
- Supports HDCP and auto EDID
- Auto switch if one computer is unpowered
- Supports Auto scan function
KVM switches allow you to control multiple computers from one keyboard, video monitor and mouse. The KVM supports USB mice, keyboards and HDMI displays.
Installation is simple
1. Connect computers to USB ports with a USB type A to type B cable to the KVM
2. Connect HDMI cables to the displays and KVM
3. Connect USB keyboard and mouse to the relevant ports on the back of KVM
4. The front USB port can be used for other USB devices
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Headphone outputs | 1 |
| Audio connections | Yes |
| USB connector type | USB Type-A, USB Type-B |
| HDMI ports quantity | 3 |
| HDMI version | 2.0 |
| Video port type | HDMI |
| Mouse port type | USB |
| Keyboard port type | USB |
| Number of computers controlled | 2 |
| Network | |
|---|---|
| Ethernet LAN | No |
| Performance | |
|---|---|
| Plug and Play | Yes |
| HDCP | Yes |
| Automatic switching | Yes |
| Maximum resolution | 4096 x 2160 pixels |
| HD type | 4K Ultra HD |
| Design | |
|---|---|
| LED indicators | Yes |
| Product colour | Black |
| Power | |
|---|---|
| Input voltage | 5 V |
| Power source | DC |
| System requirements | |
|---|---|
| Mac operating systems supported | Yes |
| Windows operating systems supported | Yes |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Cables included | HDMI, USB Type-A to USB Type-B |
