Axis P1388-LE Box IP security camera Indoor & outdoor 3840 x 2160 pixels Wall
Couldn't load pickup availability
- Excellent image quality in 4K
- -40 °C to 60 °C (-40 °F to 140 °F)
- Robust and impact-resistant design
- Support for AI analytics
- Built-in cybersecurity with Axis Edge Vault
This robust, outdoor camera has a clear deterrent effect. It offers excellent 8 MP image quality even in challenging light conditions. Ideal for various surveillance situations, it includes an exchangeable lens and delivers clear, sharp images you can count on.
Made for the great outdoors
This IP66-, IP67-, IK10- and NEMA 4X-rated camera can handle temperatures from -40 °C to 60 °C (-40 °F to 140 °F). A front heater ensures the lens is free of ice and fog. Plus, with barrel distortion correction and defogging functionality, it delivers clear, sharp images. AXIS P13 Weathershield Extension A is also available for extreme protection against snow or rain, and to prevent reflections. With electronic image stabilization, this robust camera ensures stable images despite vibration. Scene profiles can be automatically optimized to suit specific scenarios. Furthermore, with PoE and redundant DC power, you get flexible installation, and your data is safeguarded in the event of a power outage.
More light or less
With an exchangeable lens and i-CS support, you can quickly and easily change the lens, making this camera ideal for various surveillance situations. Use our lens calculator to select a lens that meets your specific needs. This box camera offers excellent image quality in 4K. Lightfinder 2.0 and Forensic WDR ensure true colors and great detail in challenging light or near darkness. And it offers P-Iris for images with better contrast, clarity, resolution, and depth of field. Additionally, OptimizedIR enables surveillance in total darkness up to 50 m (164 ft). And, with shock detection and a tampering alarm, you’ll be informed if there are any attempts to interfere with the camera.
Secure and powerful
AXIS P1388-LE offers Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. Built on an Axis system-on-chip, it includes a deep learning processing unit (DLPU) so you can run advanced features and powerful analytics on the edge. For instance, AXIS Object Analytics can detect and classify humans, vehicles, and types of vehicles. This DLPU also ensures improved processing and storage capabilities so you can collect and analyze even more data than before. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video.
| Performance | |
|---|---|
| Certification | UL/cUL, UKCA, CE, KC, EAC, VCCI, RCM |
| Infrared (IR) cut-off filter | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Preset points | Yes |
| PTZ modes | Digital PTZ |
| PTZ control | Yes |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Type | IP security camera |
| Design | |
|---|---|
| IK code | IK10 |
| International Protection (IP) code | IP66, IP67 |
| Protection features | Impact resistant |
| Housing material | Aluminium, Plastic |
| Product colour | White |
| Mounting type | Wall |
| Form factor | Box |
| Camera | |
|---|---|
| Camera shutter speed | 1/66500 - 2 s |
| Camera pixel size | 2 µm |
| Vertical field of view (thermal module) | 64° |
| Angle of rotation | 270° |
| Horizontal field of view (thermal module) | 122 - 46° |
| Minimum illumination | 0.13 lx |
| Image sensor | |
|---|---|
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Number of sensors | 1 |
| Sensor type | CMOS |
| Panoramic camera | |
|---|---|
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 55 dB |
| Sensor type (panoramic camera) | CMOS |
| Lens system | |
|---|---|
| Identify distance (tele) | 19.4 m |
| Detect distance (wide) | 78.7 m |
| Detect distance (tele) | 193.5 m |
| Observe distance (wide) | 31.2 m |
| Observe distance (tele) | 76.8 m |
| Recognize distance (wide) | 15.7 m |
| Recognize distance (tele) | 38.7 m |
| Identify distance (wide) | 7.9 m |
| Auto focus | Yes |
| Focal length range | 3.9 - 10 mm |
| Number of lenses | 1 |
| Night vision | |
|---|---|
| Infra-red wavelength | 850 nm |
| Number of illumination LEDs | 2 |
| LED type | IR |
| B/W night vision distance | 40 m |
| Night vision distance | 40 m |
| Night vision | Yes |
| Video | |
|---|---|
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Image stabilizer | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Noise reduction | Yes |
| Video streaming | Yes |
| Frame rate | 30 fps |
| Supported graphics resolutions | 160 x 90, 3840 x 2160 |
| Video formats supported | H.264, H.265 |
| Maximum resolution | 3840 x 2160 pixels |
| Audio | |
|---|---|
| Audio detection | Yes |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Sample rate | 48 kHz |
| Audio formats supported | AAC, G.711, OPUS, PCM |
| Audio system full duplex | Yes |
| Audio system | 1-way |
| Network | |
|---|---|
| Streaming method | Multicast |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2 , HTTP/ 2, TLS 2 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP,NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/ 5424, UDP/TCP/TLS), Link-Local address (ZeroConf), IEEE 802.1X (EAP-TLS), IEEE 802.1AR |
| Networking standards | IEEE 802.1x |
| Ethernet LAN | Yes |
| Storage | |
|---|---|
| Internal memory | 2048 MB |
| Flash memory | 8192 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| Ports & interfaces | |
|---|---|
| DC-in jack | Yes |
| Terminal block port | Yes |
| Microphone in | Yes |
| Security | |
|---|---|
| Human and vehicle targets classification | Yes |
| Video motion detection | Yes |
| Power | |
|---|---|
| DC output voltage | 10, 28 |
| Power consumption (max) | 25.5 W |
| Power consumption (typical) | 9.1 W |
| Power source type | PoE |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 5 - 95% |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating temperature (T-T) | -40 - 60 °C |
| Weight & dimensions | |
|---|---|
| Weight (with stand) | 3.34 kg |
| Weight | 2.46 kg |
| Sustainability | |
|---|---|
| Compliance certificates | Trade Agreements Act (TAA) |
| Packaging content | |
|---|---|
| Manual | Yes |
| Number of cameras | 1 |
| Technical details | |
|---|---|
| Safety warning | CAN/CSA C22.2 No. 62368-1 ed. 3,IEC/EN/UL 62368-1 ed. 3, IS 13252 |
| Other features | |
|---|---|
| Doesn't contain | BFR, CFR, PVC |
