£1,172.99

Stock Available: 0
  • Latest sensor technology with 12 MP resolution
  • Camera-side dewarped views
  • Built-in IR with individual IR LEDs
  • Next-generation video and audio analytics
  • Built-in cybersecurity with Axis Edge Vault

This AI-powered camera uses the latest sensor technology to provide high-quality image resolution 24/7. It includes camera-side dewarped views. And with AXIS Audio Analytics, you’ll know whenever something relevant happens, even when there's no visual indication.

Sharp images with great details
Using the latest sensor technology, AXIS M4348-PLVE offers 30% higher resolution than previous generations, reaching up to 3536x3536 pixels. Stereographic lens and Sharpdome 360 deliver outstanding image sharpness towards the edges and excellent corner image quality. It offers complete 180° or 360° coverage with no blind spots. Day/night functionality and built-in IR illumination ensure clear, reflection-free footage and excellent images even in low light or complete darkness. It supports up to four digital PTZ views, as well as panoramic, quad, corner, and corridor dewarped views. Furthermore, Axis Zipstream with AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements.

Powerful video and audio analytics
This AI-based camera comes with AXIS Object Analytics preinstalled to detect, classify, track, and count objects. Now combined with ARTPEC-9, this application offers enhanced performance with greater accuracy. Plus, AI models are specifically trained for 360° fisheye views to ensure optimized performance. With built-in microphones and AXIS Audio Analytics preinstalled, it can detect critical sounds such as glass breaking, screams, and shouts, and measure noise pollution. Plus, directional audio detection provides the direction of the audio source and a visual overlay showing exactly where the sound is coming from.

Secure and easy- indoors and out
AXIS M4348-PLVE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations. With digital roll functionality, you can remotely adjust the rotation of the camera overview– no need to do it manually on each camera. It’s also delivered factory-focused for ease of installation. And it’s discreet, compact, flat design blends seamlessly into any environment. What’s more, this robust, IK10-, IP66-, and NEMA 4X-rated outdoor-ready camera is both vandal- and impact-resistant and has an operating temperature range from -40°C to 50 °C (-40°F to 122°F).

Performance
Type IP security camera
Placement supported Indoor & outdoor
Connectivity technology Wired
PTZ control Yes
PTZ modes Preset point, Digital PTZ
Preset points Yes
Wide Dynamic Range (WDR) Yes
Infrared (IR) cut-off filter Yes
Day/night mode Yes
Processor model ARTPEC-9
Number of languages 19
Languages support English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese, Dutch, Czech, Swedish, Finnish, Turkish, Thai, Vietnamese
Dynamic range 120 dB
Design
Form factor Dome
Mounting type Ceiling/wall
Product colour White
Housing material Polycarbonate (PC), Aluminium
International Protection (IP) code IP66
IK code IK10
Camera
Minimum illumination 0 lx
Lens viewing angle, horizontal 185°
Lens viewing angle, vertical 185°
Camera pixel size 2 µm
Camera shutter speed 1/111000 - 2 s
Image sensor
Sensor type CMOS
Number of sensors 1
Optical sensor size 25.4 / 1.6 mm (1 / 1.6")
Progressive scan Yes
Lens system
Number of lenses 1
Maximum aperture number 2
Closest focusing distance 0.1 m
Fixed focal length 1.7 mm
Night vision
Night vision Yes
Night vision distance 20 m
LED type IR
Infra-red wavelength 850 nm
Video
Maximum resolution 3536 x 3536 pixels
Total megapixels 12 MP
Video compression formats H.264, MPEG4, H.265, M-JPEG, AV1
Frame rate 30 fps
Video streaming Yes
Gain control type Auto
Bit rate control Variable Bit Rate (VBR)
Image quality adjustment Saturation, Contrast, Brightness, White balance, Mirror
Privacy masking Yes
Audio
Built-in speaker(s) Yes
Audio formats supported LPCM, AAC, AAC-LC, G.711, G.726, OPUS
Signal-to-Noise Ratio (SNR) 55 dB
Built-in microphone Yes
Network
Ethernet LAN Yes
Wi-Fi No
Bluetooth No
Ethernet interface type Gigabit Ethernet, Fast Ethernet
Networking standards IEEE 802.1x, IEEE 802.1AE, IEEE 802.3at
Supported network protocols Pv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, PTP, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf)
Storage
Built-in HDD No
Card reader integrated Yes
Compatible memory cards MicroSD (TransFlash), MicroSDXC, MicroSDHC
Flash memory 8000 MB
Internal memory 4000 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Terminal block port Yes
Security
Privacy protection Yes
Security algorithms FIPS 140-2, FIPS 140-3, AES, 802.1x RADIUS, EAP-TLS, PEAP, MSCHAPv2, HTTPS, TLS
Management features
Web-based management Yes
Cloud-managed Yes
Power
Power source type PoE, DC
Power consumption (typical) 7.1 W
Power consumption (max) 16.7 W
Operational conditions
Operating temperature (T-T) -40 - 50 °C
Storage temperature (T-T) -40 - 65 °C
Operating relative humidity (H-H) 10 - 100%
Storage relative humidity (H-H) 5 - 95%
Weight & dimensions
Height 70 mm
Diameter 14.9 cm
Weight 880 g
Sustainability
Compliance certificates Federal Communications Commission (FCC), cUL, UL, CE, KC, RCM, VCCI, Electromagnetic Compatibility (EMC), ICES, RoHS, REACH
Packaging content
Number of cameras 1
Technical details
Iris Yes
Other features
Doesn't contain PVC, Brominated Flame Retardant (BFR), CFR
