Axis M3128-LVE Dome IP security camera Outdoor 3840 x 2160 pixels Ceiling
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £224.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Great image quality in 4K
- WDR and OptimizedIR
- Available in black or white
- AI-based video analytics
- Built-in cybersecurity with Axis Edge Vault
This turret-style, AI-powered dome camera delivers great 8 MP image quality. With AXIS Object Analytics it can detect and classify objects like humans and vehicles. It offers flexible installation both indoors and outdoors.
Great image quality
AXIS M3128-LVE offers great 8 MP resolution with 110° field of view. Built-in OptimizedIR allows for surveillance in complete darkness up to 20 m (65 ft) or more depending on the scene. So, there’s no need for extra lighting—you get unobtrusive surveillance both day and night. In addition, WDR preserves details when there are both light and dark areas in a scene.
Powerful with strong security
Including a deep learning processing unit (DLPU), this AI-based camera lets you run powerful analytics on the edge. For instance, it comes preinstalled with AXIS Object Analytics to detect, classify, track and count objects like humans and vehicles. This DLPU also delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video. Furthermore, Axis Edge Vault, a hardware-based cybersecurity platform, safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations.
Flexible and outdoor-ready
This flat-faced dome is designed to suppress light reflections and deliver great image quality and usability. It offers flexible installation both indoors and outdoors. Plus, with a versatile set of mounting accessories including pendant kits, conduit back boxes, and recessed mount kits, it can be mounted on walls or ceilings. Compact and discreet, it’s available in black or white to blend in with different environments. Additionally, this weatherproof camera is IP66-rated and has an operating temperature range from -30 °C to 50 °C (-22 °F to 122 °F).
Specifications
Performance
| Certification | CSA, UL/cUL, BIS, CE, KC, EAC, VCCI, RCM, BSMIEN 55024, EN 55035, EN 55032 Class A, EN 61000-6-1,EN 61000-6-2Australia/New Zealand: RCM AS/NZS CISPR 32 Class ACanada: ICES(A)/NMB(A)Japan: VCCI Class AKorea: KC KN35, KC KN32 Class A, KS C 9835,KS C 9832 Class AUSA: FCC Part 15 Subpart B Class A |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Day/night mode | Yes |
| Wide Dynamic Range (WDR) | Yes |
| PTZ modes | Digital PTZ |
| PTZ control | Yes |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Type | IP security camera |
Design
| Weatherproof | Yes |
|---|---|
| IK code | IK08 |
| International Protection (IP) code | IP66 |
| Protection features | Impact resistant, Weather resistant |
| Housing material | Plastic |
| Product colour | Black |
| Mounting type | Ceiling |
| Form factor | Dome |
Show all 81 specificationsShow fewer specifications
Camera
| Camera shutter speed | 1/71500 - 2 s |
|---|---|
| Camera pixel size | 1.45 µm |
| Pan range | -180 - 180° |
| Tilt angle range | 0 - 60° |
| Vertical field of view (thermal module) | 60° |
| Angle of rotation | 95° |
| Horizontal field of view (thermal module) | 110° |
| Minimum illumination | 0.22 lx |
Image sensor
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
|---|---|
| Number of sensors | 1 |
| Sensor type | CMOS |
Panoramic camera
| Signal-to-Noise Ratio (SNR) (panoramic camera) | 55 dB |
|---|---|
| Sensor type (panoramic camera) | CMOS |
Lens system
| Normal focusing range | 0.5 m |
|---|---|
| Detect distance (wide) | 80 m |
| Observe distance (wide) | 31.7 m |
| Recognize distance (wide) | 16 m |
| Identify distance (wide) | 8 m |
| Focal length range | 2.9 mm |
| Number of lenses | 1 |
Night vision
| Infra-red wavelength | 850 nm |
|---|---|
| LED type | IR |
| Night vision distance | 20 m |
| Night vision | Yes |
Video
| Video streaming | Yes |
|---|---|
| Frame rate | 15 fps |
| Supported video modes | 1080p |
| Supported graphics resolutions | 160 x 90, 3840 x 2160 |
| Video compression formats | MPEG, MPEG4 |
| Video formats supported | AVC, H.264, H.265, HEVC |
| Maximum resolution | 3840 x 2160 pixels |
Audio
| Signal-to-Noise Ratio (SNR) | 55 dB |
|---|---|
| Sample rate | 48 kHz |
| Audio formats supported | AAC-LC, ADPCM, LPCM, PCM |
| Audio system | 2-way |
| Built-in speaker(s) | Yes |
Network
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS2 , HTTP/ 2, TLS2 , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
|---|---|
| Networking standards | IEEE 802.1AE, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
Storage
| Internal memory | 2048 MB |
|---|---|
| Flash memory | 512 MB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
Security
| Human and vehicle targets classification | Yes |
|---|---|
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| Intelligent Video Surveillance (IVS) system features | Human detection, Vehicle detection |
| Digest authentication | Yes |
| Security algorithms | HTTPS |
| Pixel counter | Yes |
| Password protection | Yes |
Power
| Power consumption (max) | 10.5 W |
|---|---|
| Power consumption (typical) | 4.3 W |
| Power source type | PoE |
Operational conditions
| Storage relative humidity (H-H) | 5 - 95% |
|---|---|
| Operating relative humidity (H-H) | 10 - 100% |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating temperature (T-T) | -30 - 50 °C |
Weight & dimensions
| Weight | 390 g |
|---|---|
| Diameter | 10.1 cm |
| Height | 93 mm |
Sustainability
| Compliance certificates | Electromagnetic Compatibility (EMC), Trade Agreements Act (TAA) |
|---|
Packaging content
| Manual | Yes |
|---|---|
| Number of cameras | 1 |
Other features
| Doesn't contain | PVC |
|---|
