Axis · MPN: 02196-001
£360.99
inc. VAT
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £120.33 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Key specs

  • Internal memory1024 MB
  • Weight195 g
All specifications

Out of stock

FREE delivery

Express £9.99

Price drop alert

Axis FA51 1 channels 1920 x 1080 pixels
Now £360.99

We'll only use your email for this alert unless you tick the box. Unsubscribe any time.

We'll watch the price for 6 months and email you if it drops. Unsubscribe in one click.

Overview

  • 1 configurable input/output port; AXIS Face Detector preinstalled; Compatible with all AXIS FA sensor units; HDMI output for public viewing monitors; HDTV 1080p at full frame rate

This modular single-channel main unit can connect to one sensor unit offering highly discreet surveillance. Featuring an HDMI output, it’s possible to display live video on a public viewing monitor. And, AXIS Face Detector highlights faces within bounding boxes to let would-be shoplifters know they’re being monitored and proactively reduce shoplifting. Compatible with all AXIS FA sensor units including IR sensor units, you’ll enjoy excellent video quality even in complete darkness. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.

Specifications

Performance

Video formats supportedH.264
Live viewYes
PTZ controlYes
Internal memory1024 MB
Built-in processorYes
Resolution at capture speed1920x1080@480fps
Maximum frame rate30 fps
Maximum video resolution1920 x 1080 pixels
Alarm output channels2
Alarm input channels2
Channels quantity1 channels

Features

CertificationEN 55035, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2,FCC 15 B / A, ICES-3(A)/NMB-3(A),KC KN32 A, KC KN35, RCM AS/NZS CISPR 32 A,VCCI AIEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1IEC/EN 60529 IP4X, IEC 60068-2-1, IEC 60068-2-2,IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27,IEC 60068-2-78NIST SP500-267
LED indicatorsStatus
Housing materialAluminium
Product colourBlack
Show all 42 specificationsShow fewer specifications

Storage

Storage media typeFlash
Internal storage capacity0.5 GB

Network

Supported network protocolsIPv4, IPv6, USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTP, SRTP, TCP, RTCP, DHCP, SOCKS, SSH, CDP, MQTT, Syslog, Link-Local address (ZeroConf)
Networking standardsIEEE 802.1x, IEEE 802.3af
Cabling technology10/100Base-T(X)
Ethernet LAN data rates10,100 Mbit/s

Management features

SyslogYes
Access Control List (ACL)Yes
Web-based managementYes

Ports & interfaces

Ethernet LAN (RJ-45) ports1
Number of HDMI outputs1

Power

Power consumption (max)6.82 W
Power consumption (min)5.2 W
Power over Ethernet (PoE)Yes

Operational conditions

Storage relative humidity (H-H)10 - 85%
Storage temperature (T-T)-40 - 65 °C
Operating relative humidity (H-H)10 - 85%
Operating temperature (T-T)-20 - 50 °C

System requirements

Browser supportedChrome, Edge, Firefox, Safari

Weight & dimensions

Weight195 g
Height24 mm
Depth152 mm
Width49 mm

Packaging content

ManualYes

Technical details

Doesn't containBrominated Flame Retardant (BFR), CFR, PVC
Warranty period5 year(s)

Certificates

Waste Electrical and Electronic Equipment (WEEE) complianceYes
