ATEN RCM464VA KVM switch Black
Now £15,691.99

We'll only use your email for this alert unless you tick the box. Unsubscribe any time.

We'll watch the price for 6 months and email you if it drops. Unsubscribe in one click.

Overview

  • Black
  • Number of computers controlled: 64
  • Keyboard port type: USB Mouse port type: USB Video port type: HDMI/VGA
  • Full HD+ 1920 x 1200 pixels
  • Housing material: Metal
  • Hot keys
  • AC

The RCM Series of KVM over IP switches RCM464VA provides local console and remote over IP access for users to monitor and access their entire data center over a network. The RCM series offers superior FHD video resolution up to 1920 x 1200, virtual media transmissions at double speed, FIPS 140-2 with level 1 security standards by using an embedded FIPS 140-2 certified OpenSSL cryptographic module. Equipped with dual on-board NICs, the RCM series is built to ensure reliability and availability of remote access to all servers. The RCM series can be remotely accessed via WinClient / JavaClient* at a console from a separated location for management and operation.

The RCM series is compatible with ATEN’s KVM over IP Console Station – the KA82 series. The KA82 series is a standalone console that replaces PC or NB, enabling users to remotely access, monitor and control all servers connected to multiple ATEN’s RCM series with impenetrable security against virus threats. It is especially suitable for environments where a PC is not allowed. In addition, the RCM series works with ATEN’s PDU remote power management systems from the KVM over IP switches’ user interface.

Integrated with ATEN's exclusive RCM API, the RCM series delivers optimal OCR functionality and customizable system integration and automation. Additionally, by using the RCMMS (RCM Management Software), an intuitive, centralized management platform featuring Panel Array, users can manage, monitor, and control up to hundreds of RCM devices simultaneously.

To ensure seamless connectivity, the RCM series is equipped with dual LAN and dual power capability for keeping operation at the production line smooth and efficient.

All in all, the RCM series provides a complete system management across different facilities reduces the number of operators required on site to minimize space requirement while maximizing personnel efficiency. With its over-IP access eliminating the need to physically move legacy KVM solution to each malfunctioning unit, providing users with the ability to capture the device display screen data for data collection and direct OCR analysis, and using APIs for software integration applications, it is an outstanding solution for high-tech production lines requiring durable and reliable over-IP server management.

Note:
We recommend using WinClient app or JavaClient app for more robust management and control. Performance and usage may vary depending on the user's hardware configuration. A minimum of 8GB RAM, dual core CPU and a graphics card that supports OpenGL is required. Please also make sure that the browser is the latest version.

Specifications

Ports & interfaces

AC-in ports quantity2
Number of microphone inputs1
Headphone outputs1
Audio connectionsYes
USB connector typeMini-USB B, USB Type-A
Console HDMI ports quantity1
Console portsHDMI, Mini-USB B, RJ–45, USB A, VGA (D-Sub)
Console USB ports quantity2
VGA (D-Sub) ports quantity1
HDMI ports quantity1
Video port typeHDMI/VGA
Mouse port typeUSB
Keyboard port typeUSB
Number of computers controlled64

Network

Security algorithmsFIPS 140-2
Cabling technology10/100/1000Base-T(X)
Ethernet LAN (RJ-45) ports68
Ethernet LANYes
Show all 46 specificationsShow fewer specifications

Performance

Number of users64 user(s)
Scan interval255 s
Video bandwidth60 Hz
Maximum resolution1920 x 1200 pixels
HD typeFull HD+

Design

Hot keysYes
Push buttonYes
LED indicatorsYes
Housing materialMetal
Product colourBlack

Display

On Screen Display (OSD)Yes
Built-in displayNo

Power

Input current1 A
AC input frequency50/60 Hz
Input voltage100 - 240 V
Power sourceAC

System requirements

Mac operating systems supportedYes
Linux operating systems supportedYes
Windows operating systems supportedYes

Operational conditions

Operating relative humidity (H-H)0 - 80%
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C

Weight & dimensions

Weight7.08 kg
Height88 mm
Depth433.9 mm
Width412.6 mm

Packaging content

ManualYes
Cables includedAC
