ASUS · MPN: 90SF02E1-M00710
£4,408.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £1,469.66 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Powerful performance: Powered by AMD EPYC 9004 processors with 128 Zen 4c cores, 12-channel, up to 4800 MHz DDR5 and support for a maximum TDP of up to 400 watts per socket
  • Scale-up storage and expansion design: A total of 24 bays in combination of Tri-Mode NVMe/SATA/SAS drives on the front panel and nine PCIe 5.0 slots for higher bandwidth and system upgrade
  • Flexible networking module design: Optional two 10 Gbps or four 1 Gbps on-board LAN module, and OCP 3.0 module with PCIe 5.0 slot in rear panel for faster connectivity
  • Advanced air cooling solution: Features enhanced volume air cooling (EVAC) heatsink for processors with higher TDP
  • Enhanced IT-infrastructure management: ASUS ASMB11-iKVM remote control with ASPEED AST2600, ASUS Control Center IT management software and hardware-level Root-of-Trust solution
  • Read for AI and HPC workloads: Up to three dual-slot GPU, including NVIDIA A100 and A40, AMD Instinct and Xilinx

PCIe 5.0 Ready
Faster storage, graphics and networking capabilities
PCI Express® (PCIe®) 5.0 delivers 32GT/s bandwidth, which is twice the speed of PCIe 4.0, and offers lower power consumption, better land scalability and backwards compatibility. ASUS servers are PCIe 5.0 ready with scalability design to satisfy the increasing workloads for modern data center.

Specifications

Processor

Compatible processor seriesAMD EPYC 9004
Number of processors supported2
Processor familyAMD EPYC
Processor manufacturerAMD
Processor socketSocket SP5
Built-in processorNo

Memory

Supported RDIMM clock speeds4400,4800 MHz
Maximum internal memory6 TB
Supported DIMM module capacities128GB, 64GB, 32GB
Supported memory typesDDR5-SDRAM
Number of DIMM slots24
Show all 46 specificationsShow fewer specifications

Storage

SSD form factorM.2
Supported storage drive typesHDD & SSD
Storage drive sizes supported2.5,M.2
Number of 2.5" bays24
Hot-swap HDD baysYes
Number of storage drives supported24

Graphics

On-board graphics card memory64 MB
On-board graphics card modelAspeed AST2600

Network

LAN controllerIntel X710-AT2
Ethernet LANYes
Ethernet interface type10 Gigabit Ethernet

Ports & interfaces

VGA (D-Sub) ports quantity1
IPMI LAN (RJ-45) portYes
Ethernet LAN (RJ-45) ports2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4

Expansion slots

PCI Express slots version5.0

Features

Trusted Platform Module (TPM) version2.0
Trusted Platform Module (TPM)Yes

Technical details

Compliance certificatesBSMI, CE, CB, C-TICK, Federal Communications Commission (FCC)

Design

Number of fans4 fan(s)
Cooling typeActive
Reset buttonYes
On/off switchYes
LED indicatorsYes
Product colourGrey
Chassis typeRack (2U)

Power

Redundant power supply (RPS) supportYes
Power supply2600 W

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-40 - 60 °C
Storage relative humidity (H-H)20 - 90%

Weight & dimensions

Width449 mm
Depth840 mm
Height88.1 mm
Weight18.3 kg
