ASUS · MPN: 90SF0251-M00150
£1,343,999.99
inc. VAT
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £447,999.99 See options

Credit subject to status. 18+, UK residents only. See each provider for terms.

Out of stock

FREE delivery

Express £9.99

Overview

  • Up to eleven PCIe® 4.0 slots enables higher bandwidth and improved data transfer rates
  • GPU-optimized design allows four double-slot or eight single-slot GPUs, including NVIDIA® A100, Tesla® T4 or Quadro®
  • A Xilinx Alveo-qualified server support for Alveo U50 to provide optimized acceleration for workloads across cloud and on-premises data centers
  • Supports NVIDIA® NVLink bridge to enable scaling of performance to meet the demands of visual computing workloads
  • A choice of PCIe Gen 4.0, OCP 3.0, NVMe and M.2 on the front panel offer flexibility, performance and scalability for changing business needs
  • High power efficiency with redundant 2200W or 1600W Platinum power supplies
  • ASUS thermal control technology offers more efficient power consumption for large-scale environments
  • ASUS performance tuning technology improves workload throughput to achieve optimal server performance
  • Onboard ASUS ASMB10-iKVM with ASPEED AST2600 controller for out-of-band management
  • Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
  • Two hot-plug, hot-swap fans design for fully redundancy protection and thermal efficiency

Powered by AMD EPYC™ 7003 & 7002 series processors
The AMD EPYC™ 7003 & 7002 processor features the world's first 7nm datacenter-design and a PCI Express® 4.0-capable x86 server processor with up to 2X the performance and 4X the floating-point capability. With support for up to 64 cores, 128 threads, 8-channel DDR4 3200, 128 PCIe 4.0 lanes and up to 280 watts of max. thermal design power (TDP), this processor also includes memory and virtualization encryption features to ensure exceptional security.

PCIe 4.0 expansion
PCIe® 4.0 delivers 16 GT/s bandwidth — double the speed of PCIe 3.0 — while offering lower power consumption, better lane scalability and backwards compatibility. ASUS ESC4000A-E11 features up to eleven PCIe 4.0 slots to support a diverse array of graphics, storage and networking applications, such as HBA/RAID, NIC and InfiniBand (IB) cards.

GPU and FPGA support
ESC4000A-E11 features a powerful GPU architecture that supports up to four double- slot or eight single-slot GPUs in a 2U chassis, including NVIDIA® A100 and AMD Instinct™ MI100 accelerator to meet the demands of AI and HPC, and to securely run workloads in virtualization environment. It is also a Xilinx Alveo-qualified server to provide optimized acceleration for hybrid cloud environments in financial computing, machine learning, computational storage, and data search and analytics.

Flexible front panel design
ESC4000A-E11 features a flexible front panel design that allows for easy storage and network expansions and upgrades. The design offers easier accessibility of up to four NVMe SSD drives and an optional choice of OCP 3.0, a hyper M.2 adapter or HBA/RAID card via PCIe 4.0 slot for better performance and lower latency.

NVIDIA RTX server
ESC4000A-E11 is a NVIDIA RTX server validate system that deliver unprecedented performance at a fraction of the cost, space, and power requirements of traditional CPU-based solutions, from production rendering to scalable visualization systems or HPC, AI, ML, big data analytics, and at the edge deployment options.

Ultrafast connectivity for HPC applications
ESC4000A-E11 features a OCP 3.0 NIC card to deliver speeds of up to 200 Gbps for HPC applications that require high-bandwidth, low-latency network support for connecting multiple nodes and clusters.

Scalable storage design
To effectively manage the storage demands of growing amounts of data, ESC4000A-E11 has a dense chassis design that accommodates up to eight 3.5-inch or 2.5- inch drives, including up to four NVMe SSDs support. One onboard 22110-length M.2 SSD allows faster data transfer speeds for OS installation, and a hyper M.2 card is available to provide even greater expansion capability.

Specifications

Processor

Compatible processor seriesAMD EPYC 7002, AMD EPYC 7003
Number of processors supported1
Processor socketSocket SP3
Built-in processorYes

Memory

Supported RDIMM clock speeds3200 MHz
Maximum internal memory2.05 TB
Supported DIMM module capacities16GB, 32GB, 64GB, 128GB
Supported memory typesDDR4-SDRAM
Number of DIMM slots8
Show all 34 specificationsShow fewer specifications

Storage

SSD form factorM.2
Number of 3.5" bays8
Hot-swap HDD baysYes
Number of storage drives supported8

Network

LAN controllerIntel® I350-AM2
Ethernet LANYes

Ports & interfaces

Number of SAS ports8
VGA (D-Sub) ports quantity1
Ethernet LAN (RJ-45) ports3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4

Expansion slots

PCI Express x16 slots14

Design

Product colourSilver
Chassis typeRack (2U)

Power

80 PLUS certification80 PLUS Platinum
Input current12.9 A
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Power supply1600 W

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-40 - 70 °C
Storage relative humidity (H-H)20 - 90%

Weight & dimensions

Width800 mm
Depth440 mm
Height88.9 mm
Weight34 kg
