APC Service Bypass PDU, 230V 16AMP Hardwire
£362.99
Couldn't load pickup availability
- APC SERVICE BYPASS PDU
- The Service Bypass Panels provide a wrap around system to allow maintenance of UPS isolating it from critical load.
- Includes Rack mounting brackets & User manual
- 2 years repair or replace warranty
The APC Service Bypass supports a load capacity of 3000VA. It has a nominal input and output voltage of 230V. The unit is rack-mounted, occupying 2U of rack space, and includes a circuit breaker for protection. It features a hardwire 3-wire (H N + E) connection.
| Features | |
|---|---|
| Rack capacity | 2U |
| Country of origin | India |
| Ports & interfaces | |
|---|---|
| Output connections | hard wire 3-wire (H N + E) for 1 zone(s) |
| Power | |
|---|---|
| AC output voltage | 230 V |
| AC input voltage | 230 V |
| Certificates | |
|---|---|
| Compliance certificates | RoHS, REACH, WEEE |
| Certification | VDE, REACH |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
|---|---|
| Width | 432 mm |
| Depth | 76 mm |
| Height | 89 mm |
| Weight | 2.27 kg |
| Technical details | |
|---|---|
| Preferred mounting position | no preference |
| Packaging recycled materials | Recycled cardboard |
| Mounting | front |
| Packaging without single use plastic | No |
| Take-back system | No |
| SCIP number | 7a19864b-8bf5-40ac-85e8-7678b0910185 |
| Sustainable packaging | No |
| Logistics data | |
|---|---|
| Customs product code (TARIC) | 8536699099 |
