APC
£25,090.99
Stock Available: 0
  • Up to 99% efficient in eConversion mode
  • Increase availability with modular architecture: One extra power module delivers N+1 redundancy and no footprint penalty
  • Live Swap: Third party verified module replacement with no scheduled downtime
  • EcoStruxure IT option: Enables resilient, secure, and sustainable IT environments
  • 1-year Secure NMC Subscription, allowing the customer to access future firmware updates, is included with purchase

Highly efficient, easy-to-deploy 100 kW, 400 V 3-phase UPS that brings best-in-class power protection and low total cost of ownership to edge, small and medium data centers, as well as to critical infrastructure in commercial and industrial applications. Includes 5x8 start-up service and one additional power module for N+1 redundancy.

Features
Audible alarm(s) Yes
Noise level 68 dB
Input current Total Harmonic Distortion (THD) 3%
Crest factor 2.5:1
Heat dissipation 11373 BTU/h
Maximum current 180 A
Output frequency 50/60 Hz
Output operation voltage (min) 400 V
Input frequency 40 - 70 Hz
Input operation voltage (max) 460 V
Input operation voltage (min) 340 V
Waveform Sine
Output power 100000 W
Output power capacity 100 kVA
UPS topology Double-conversion (Online)
Battery
Battery voltage 576 V
Battery technology Lithium-Ion (Li-Ion)
Design
International Protection (IP) code IP21
Product colour White
Operational conditions
Operating altitude 0 - 1005.84 m
Storage relative humidity (H-H) 10 - 80%
Operating relative humidity (H-H) 0 - 95%
Storage temperature (T-T) -25 - 55 °C
Operating temperature (T-T) 0 - 40 °C
Sustainability
Sustainability compliance Yes
Certificates
Compliance certificates RoHS
Weight & dimensions
Weight 290 kg
Height 1485 mm
Depth 847 mm
Width 521 mm
Packaging data
Package weight 315 kg
Package height 1680 mm
Package depth 990 mm
Package width 640 mm
Logistics data
Warranty period 1 year(s)
