APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3
APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3
APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3
APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3
APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3
APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3

APC Easy UPS 3S 15 kVA 400V 3:1 UPS, 2 internal 7Ah modular battery strings, expandable to 3

APC
£7,409.99
Stock Available: 0
  • Front-access servicing: simplifies installation and UPS maintenance while minimizing space requirements
  • ECO Mode: operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
  • Intuitive user interface: the intuitive graphical user interface allows for easy system configuration
  • Easy to install fast: quickly roll the compact and lightweight UPS into position
  • Easy Loop Test: verifies UPS performance before you connect your load, without the need for a load bank
  • Straightforward installation: including the input, output, and bypass breakers, as well as the Emergency Power Off (EPO) switch, simplifies installation planning and speeds up deployment
  • Optional SNMP Card: when you purchase the SNMP card, you can monitor and manage UPS status remotely through the UPS Web interface or through EcoStruxure IT's cloud-based and on-premise software suites. Click here for more information about EcoStruxure IT
  • Wide Input Voltage Window: saves your battery power for when you really need it - during power cuts!
  • Parallel capability: multiple units can be placed in parallel to meet power capacity and redundancy requirements
  • Replaceable dust filters: protect the UPS in harsh environments

Easy-to-install, easy-to-operate, easy-to-maintain, and easy-to-service 15 kVA 3:1 UPS. With advanced product features, competitive specifications, and robust electrical design, the Easy UPS 3S UPS makes business continuity easy for small and medium data centers and electrical rooms. Includes dust filter and conformance-coated boards for harsh environments, and 2 internal 7 Ah modular battery strings, expandable to 3 strings for extended runtime.

Features
UPS topology Double-conversion (Online)
Output power capacity 15 kVA
Output power 15000 W
Input operation voltage (min) 304 V
Input operation voltage (max) 477 V
Input frequency 45/65 Hz
Output operation voltage (min) 220 V
Output operation voltage (max) 240 V
Output frequency 50/60 Hz
Output voltage regulation 3%
Input power factor 0.99
Crest factor 3:1
ECO mode Yes
Output voltage Total Harmonic Distortion (THD) 5.5%
Noise level 60 dB
Power protection features Overload
Ports & interfaces
AC outlet types Hard Wire 4-wire (3PH + N)
Battery
Battery technology Sealed Lead Acid (VRLA)
Battery voltage 240 V
Number of batteries supported 2
Design
Form factor Large tower
Product colour White
International Protection (IP) code IP20
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -15 - 40 °C
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Operating altitude 0 - 984 m
Non-operating altitude 0 - 15000 m
Certificates
Certification CE, EAC, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE
Weight & dimensions
Width 380 mm
Depth 907 mm
Height 1400 mm
Weight 211 kg
Packaging data
Package width 563 mm
Package depth 1014 mm
Package height 1640 mm
Package weight 229 kg
Logistics data
Harmonized System (HS) code 85078000
