AOPEN DEX5750 Intel® Core™ i5 i5-1135G7 8 GB DDR4-SDRAM 128 GB SSD Windows 11 Mini PC Black
Spread the cost with Klarna, Clearpay, PayPal, Float or SnapFrom 3 interest-free payments of £273.66 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Key specs
- Processor modeli5-1135G7
- Memory clock speed3200 MHz
- Internal memory typeDDR4-SDRAM
- Weight1.87 kg
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Business Mini PC Black 90 W
- Intel® Core™ i5 i5-1135G7 2.4 GHz Processor cores: 4
- 8 GB DDR4-SDRAM 3200 MHz 1 x 8 GB
- 128 GB SSD
- Intel Iris Xe Graphics
- Ethernet LAN 10,100,1000 Mbit/s
- Windows 11 64-bit
The first AOPEN Intel-based system capable of supporting hardware accelerated AV1 8K playback. As if that wasn’t enough, the DEX5750 has a 12 ~ 24V DC for automotive use and a legacy RS232/422/485 COM Port selectable by BIOS, making the system very suitable for automation purposes.
8K HDR content playback
This digital signage media player is capable of driving 8K content. With a resolution that goes up to 7680 x 4320 pixels, your content is displayed clearly.
Intel® Core™ platform
This Digital Engine is based on the Intel® Core™ platform. More specifically, on the 11th generation. These computing devices are available in i3 and i5, and therefore in different SKU’s.
Small form factor
This form factor ensures easy integration into kiosks or behind screens. The AOPEN small form factor is a standard that is used for Digital Engine (DE) models. The size of our Digital Engine series is set to a maximum of 240 x 25 x 158 mm. Do the math and you will see that a Digital Engine is an investment that will last, even after replacing the item in a kiosk or mount that already exists.
Fanless design without venting holes
This Digital Engine is passively cooled. The cooling ribs on its exterior make sure the device won’t overheat. This means the device doesn’t have moving parts which enhance its reliability. Furthermore, the device is quiet and dustproof.
Specifications
Processor
| Processor base power | 12 W |
|---|---|
| Maximum turbo power | 28 W |
| Number of processors installed | 1 |
| Configurable TDP-down | 12 W |
| Configurable TDP-down frequency | 0.9 GHz |
| Configurable TDP-up frequency | 2.4 GHz |
| Configurable TDP-up | 28 W |
| Processor cache type | Smart Cache |
| Processor cache | 8 MB |
| Processor frequency | 2.4 GHz |
| Processor boost frequency | 4.2 GHz |
| Processor threads | 8 |
| Processor cores | 4 |
| Processor model | i5-1135G7 |
| Processor generation | 11th gen Intel® Core™ i5 |
| Processor family | Intel® Core™ i5 |
| Processor manufacturer | Intel |
Memory
| Memory channels | Dual-channel |
|---|---|
| Memory clock speed | 3200 MHz |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 1 x 8 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 64 GB |
| Internal memory | 8 GB |
Show all 72 specificationsShow fewer specifications
Storage
| Card reader integrated | No |
|---|---|
| SSD form factor | M.2 |
| SSD capacity | 128 GB |
| Number of SSDs installed | 1 |
| Total SSDs capacity | 128 GB |
| Storage media | SSD |
| Optical drive type | No |
| Total storage capacity | 128 GB |
Graphics
| On-board graphics card model | Intel Iris Xe Graphics |
|---|---|
| On-board graphics card family | Intel Iris Xe Graphics |
| On-board GPU manufacturer | Intel |
| Discrete graphics card model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
Network
| Wi-Fi | No |
|---|---|
| LAN controller | Intel I225-LM |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN | Yes |
Ports & interfaces
| Serial ports quantity | 2 |
|---|---|
| Line-out | Yes |
| Line-in | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 2 |
| HDMI version | 2.0 |
| HDMI ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
Design
| Product colour | Black |
|---|---|
| Cable lock slot | Yes |
| VESA mounting | Yes |
| Volume | 0.95 L |
| Chassis type | Mini PC |
Performance
| Audio chip | Realtek ALC897 |
|---|---|
| Market positioning | Business |
| Product type | Mini PC |
Software
| Operating system architecture | 64-bit |
|---|---|
| Operating system installed | Windows 11 |
Processor special features
| CPU configuration (max) | 1 |
|---|
Power
| Power supply input voltage | 100 - 240 V |
|---|---|
| Power supply | 90 W |
Operational conditions
| Operating relative humidity (H-H) | 0 - 90% |
|---|---|
| Storage temperature (T-T) | -30 - 60 °C |
| Operating temperature (T-T) | -20 - 45 °C |
Weight & dimensions
| Weight | 1.87 kg |
|---|---|
| Height | 25 mm |
| Depth | 158 mm |
| Width | 240 mm |
Packaging content
| Display included | No |
|---|
