Intel Core i3-14100T processor 12 MB Smart Cache

Intel

£138.92

Stock Available: 0

Product Information

Processor
Processor ARK ID	236775
Processor codename	Raptor Lake
Memory bandwidth supported by processor (max)	76.8 GB/s
Maximum number of DMI lanes	8
Stepping	H0
Processor base power	35 W
Maximum turbo power	69 W
Processor cache type	Smart Cache
Processor cache	12 MB
Performance-core base frequency	2.7 GHz
Performance-core boost frequency	4.4 GHz
Processor boost frequency	4.4 GHz
Performance cores	4
Processor operating modes	64-bit
Processor threads	8
Box	No
Processor socket	LGA 1700
Processor cores	4
Processor model	i3-14100T
Processor generation	Intel® Core™ i3 (14th gen)
Processor family	Intel® Core™ i3
Processor manufacturer	Intel

Memory
Memory bandwidth (max)	76.8 GB/s
Memory channels	Dual-channel
Memory types supported by processor	DDR4-SDRAM, DDR5-SDRAM
Maximum internal memory supported by processor	192 GB

Graphics
Multi-Format Codec Engines	1
Number of execution units	24
Discrete graphics card model	Not available
On-board graphics card ID	0x4692
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
Number of displays supported (on-board graphics)	4
On-board graphics card dynamic frequency (max)	1500 MHz
On-board graphics card outputs supported	Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card model	Intel UHD Graphics 730
On-board graphics card	Yes
Discrete graphics card	No

Features
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Export Control Classification Number (ECCN)	5A992C
Scalability	1S
Embedded options available	Yes
Direct Media Interface (DMI) Revision	4.0
CPU configuration (max)	1
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
PCI Express configurations	1x16+1x4, 2x8+1x4
PCI Express slots version	4.0, 5.0
Maximum number of PCI Express lanes	20
Use conditions	PC/Client/Tablet
Market segment	Desktop
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes

Processor special features
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel 64	Yes
Intel® Standard Manageability (ISM)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Volume Management Device (VMD)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Secure Key	Yes
Intel® OS Guard	Yes
Intel® Boot Guard	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Speed Shift Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Enhanced Intel SpeedStep Technology	Yes

General
Product family	Core
Product series	i3

Operational conditions
Tjunction	100 °C

Logistics data
Harmonized System (HS) code	8542310001

Weight & dimensions
Processor package size	45 x 37.5 mm
