Vertiv Liebert GXT5LI-5000GVRT3UXLN uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 5000 W
Couldn't load pickup availability
- Lithium-Ion UPS batteries last up to 3x longer than VRLA batteries
- Offers lowest total cost of ownership (TCO) with fewer or no battery replacements over its lifetime
- Environmentally friendly UPS reduces battery disposal and recycling with lower replacement rates
- Longer runtime, faster recharge time and scalable runtime with external battery cabinets
- Integrated MBC allows the user to power connected equipment even during UPS maintenance or replacement
The Vertiv Liebert GXT5 Lithium-Ion UPS protects critical IT applications against outages and various power disturbances. This online UPS offers the highest level of power conditioning and battery backup in server rooms, network closets, and other edge or distributed IT locations. Lithium-Ion batteries require fewer battery replacements and last up to 3x as long as traditional VRLA batteries reducing maintenance, labor, and replacement costs (resulting in the lowest TCO). The battery offers industry-leading runtime to protect critical equipment during an unexpected power loss. It also gives better performance at higher temperatures, supports up to 10 times more discharge cycles, and delivers faster recharge times. It is hot-swappable and user-replaceable, so you can easily replace it without disrupting power to connected equipment. The Integrated Maintenance Bypass Cabinet (MBC) allows the user to continue to power connected equipment even during UPS maintenance or replacement.
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 5000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 176 V |
| Input operation voltage (max) | 288 V |
| Input frequency | 40 - 70 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Efficiency | 94% |
| Output power factor | 1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Noise level | 56 dB |
| Surge protection | Yes |
| Power protection features | Over voltage, Under voltage |
| Ports & interfaces | |
|---|---|
| USB port | Yes |
| Serial ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Battery | |
|---|---|
| Battery technology | Lithium-Ion (Li-Ion) |
| Typical backup time at full load | 11 min |
| Typical backup time at half load | 25 min |
| Battery recharge time | 2 h |
| Hot-swap battery | Yes |
| Design | |
|---|---|
| Form factor | Rackmount/Tower |
| Product colour | Black |
| Rack capacity | 3U |
| Display type | LCD |
| General | |
|---|---|
| Product family | Liebert |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating altitude | 0 - 3000 m |
| Safety regulation & standards | |
|---|---|
| Safety | IEC 62040-1:2008+A1 2013, IEC 62619 1st Ed., UL 1642 (Li-Ion Battery Cells), UL 1973 (Li-Ion Battery Pack w/UPS), UL 1778, CSA 22.2 No. 107.3 |
| Sustainability | |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Packaging content | |
|---|---|
| Batteries included | Yes |
| Certificates | |
|---|---|
| Compliance certificates | REACH, RoHS, WEEE |
| Weight & dimensions | |
|---|---|
| Width | 430 mm |
| Depth | 890 mm |
| Height | 133 mm |
| Weight | 23 kg |
| Packaging data | |
|---|---|
| Package width | 798 mm |
| Package depth | 998 mm |
| Package height | 532 mm |
| Package weight | 72 kg |
| Logistics data | |
|---|---|
| Country of origin | China |
