Vertiv Liebert GXE3-10KIRT5UXL uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
Couldn't load pickup availability
- Reliable double-conversion online topology with zero transfer time
- Unity output power factor (1.0) to protect more loads
- Hot-swappable user replaceable batteries
- Remote management and server shutdown with the optional network management card
- Fast recharge time (3 hours at 90%) and scalable runtime capabilities
The Vertiv Liebert GXE UPS is an affordable, efficient UPS designed for delivering best-in-class power protection to equipment at the edge of networks or in remote sites. This 10000 VA UPS offers online double conversion solution. Its unity output power factor (1.0) enables continuous and reliable power to more connected devices. The high efficiency in both online and ECO modes of operation (up to 98% in ECO mode) for this already affordable UPS further drives energy and operational costs savings. Additional external battery cabinets provide scalable runtime for those applications requiring longer period of backup in case of AC mains failures. This single-phase UPS can be mounted as a tower or placed inside a rack cabinet, with a gravity sensing LCD display to allow rack/tower configurations. It has remote management capability with optional network management cards. With proven reliability, it is ideal for critical applications in financial, government, and manufacturing industries.
| Features | |
|---|---|
| Audible alarm(s) | Yes |
| Power protection features | Overload |
| EMI/RFI noise filtering | Yes |
| Emergency Power Off (EPO) | Yes |
| Efficiency (ECO mode) | 98% |
| Efficiency (On-line mode) | 94% |
| Surge energy rating | 600 J |
| Output operation voltage (max) | 230 V |
| Output operation voltage (min) | 220 V |
| Input frequency | 40/70 Hz |
| Input operation voltage (max) | 288 V |
| Input operation voltage (min) | 178 V |
| Waveform | Pure sine |
| Output power | 10000 W |
| Output power capacity | 10 kVA |
| UPS topology | Double-conversion (Online) |
| Ports & interfaces | |
|---|---|
| USB port | Yes |
| Battery | |
|---|---|
| Battery life (max) | 5 year(s) |
| Battery technology | Sealed Lead Acid (VRLA) |
| Design | |
|---|---|
| Display type | LCD |
| Rack capacity | 5U |
| Product colour | Black |
| Form factor | Tower |
| General | |
|---|---|
| Product family | Liebert |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Certificates | |
|---|---|
| Certification | CE, UKCA, Morocco, RCM, CB report, EAC |
| Compliance certificates | REACH, RoHS, WEEE |
| Packaging content | |
|---|---|
| Quick installation guide | Yes |
| Cables included | USB cable |
| Rack mount kit | Yes |
| Weight & dimensions | |
|---|---|
| Weight | 80 kg |
| Height | 217 mm |
| Depth | 700 mm |
| Width | 430 mm |
| Packaging data | |
|---|---|
| Package weight | 102 kg |
| Package height | 530 mm |
| Package depth | 800 mm |
| Package width | 600 mm |
| Logistics data | |
|---|---|
| Country of origin | China |
| Other features | |
|---|---|
| Nominal input voltage | 230 V |
