Veracity VLS-1N-L network extender Network transmitter & receiver Silver 10, 100 Mbit/s

Veracity VLS-1N-L network extender Network transmitter & receiver Silver 10, 100 Mbit/s

Veracity
£227.99
Stock Available: 0
  • Long range point-to-point Ethernet over Cat5e or Cat6 cable
  • Unrestricted 100Base-TX at up to 820 metres
  • Ruggedised, high performance over a wide temperature range
  • Designed to connect locally-powered IP devices
  • Compatible with all LONGSPAN model variants
  • Fully automatic, simple to install and maintenance-free

LONGSPAN Lite self-configures for optimum performance across 4-pair, 2-pair or 1-pair data-only links. The Lite version can be used in combination with another Lite device or with LONGSPAN POE devices at the camera end which are locally powered for maximum POE output.

A pair of LONGSPAN Lite network adaptors deliver full bandwidth Ethernet over greatly extended distances of regular network cable. No POE is transmitted and both devices are powered by 12V DC at each end.

Performance
Type Network transmitter & receiver
Maximum transfer distance 1050 m
Data transfer rate 200 Mbit/s
Cable types supported Cat3, Cat5e, Cat6
Ethernet LAN data rates 10,100 Mbit/s
Duplex system Full
Auto MDIX IEEE Yes
Auto-negotiation Yes
Plug and Play Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports 2
Design
Product colour Silver
Quantity per pack 1 pc(s)
Power
AC input voltage 20 - 28 V
Power consumption (typical) 1 W
External power adapter Yes
Operational conditions
Operating temperature (T-T) -40 - 70 °C
Storage temperature (T-T) 0 - 85 °C
Weight & dimensions
Width 36 mm
Depth 120 mm
Height 23 mm
Weight 100 g
Packaging data
Package type Box
Package width 137 mm
Package depth 62 mm
Package height 30 mm
Package weight 111 g
