Ubiquiti USW-ENTERPRISE-24-POE network switch Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Silver
iFrame
£720.99
Couldn't load pickup availability
- (12) 2.5G 802.3af/at PoE+ RJ45 ports
- (12) 1G 802.3af/at PoE+ RJ45 ports
- (2) 10G SFP+ ports
- 400W total PoE capacity
- 1.3" touchscreen with AR switch management
- UniFi SmartPower RPS DC input
Managed Layer 3 switch with (12) 2.5G RJ45 ports with PoE+ for WiFi 6 APs, (12) Gigabit RJ45 ports with PoE+, and (2) 10G SFP+ ports for fiber uplinks.
Configurable Gigabit Layer 3 switch with auto-sensing 802.3at PoE+. It offers (12) 2.5G RJ45 Ethernet ports, (12) 1G RJ45 Ethernet ports, and (2) 10G SFP+ ports, providing 2.5G PoE links to your WiFi 6 APs and 10G fiber uplinks to your network. Features include a 1.3" touchscreen, single-row RJ45 port layout for easy patch panel cable management, and UniFi SmartPower Redundant Power System* (USP-RPS) support for intelligent protection from internal PSU interruption or failure.
| Management features | |
|---|---|
| Switch layer | L3 |
| Switch type | Managed |
| Ports & interfaces | |
|---|---|
| Installed SFP+ modules quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Network | |
|---|---|
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| 10G support | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Data transmission | |
|---|---|
| Forwarding rate | 92.25 Mpps |
| Switching capacity | 124 Gbit/s |
| Design | |
|---|---|
| LED indicators | Activity, Link, System |
| Housing material | Galvanized steel |
| Product colour | Silver |
| Rack mounting | Yes |
| Power | |
|---|---|
| Power consumption (max) | 550 W |
| DC input voltage | 11.5 - 52 V |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply included | Yes |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) power per port | 34.2 W |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | 10 - 95 °C |
| Operating temperature (T-T) | -5 - 40 °C |
| Weight & dimensions | |
|---|---|
| Weight | 5.11 kg |
| Height | 43.7 mm |
| Depth | 325 mm |
| Width | 442.4 mm |
| Packaging content | |
|---|---|
| Rack mount kit | Yes |
| Certificates | |
|---|---|
| Certification | CE, FCC, IC |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
