Ubiquiti NanoStation 5AC Loco 450 Mbit/s White Power over Ethernet (PoE)
iFrame
£206.99
Couldn't load pickup availability
- New antenna
- Improved design
- Management WiFi Radio/UNMS mobile app
- AirOS 8
Classic NanoStation design with updated proprietary airMAX ac chipset and dedicated management Wi-Fi for easy UNMS mobile app support and fast setup. Excellent solution for a simple PtP bridge or use as a PtMP station (CPE).
Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
| Features | |
|---|---|
| Maximum outdoor range | 10000 m |
| Quality of Service (QoS) support | Yes |
| Modulation | 16-QAM, 64-QAM, 256-QAM, BPSK, QPSK |
| MIMO | Yes |
| Frequency band | 5 GHz |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 450 Mbit/s |
| 5 GHz | Yes |
| Security | |
|---|---|
| Security algorithms | WPA2 |
| Management features | |
|---|---|
| Web-based management | Yes |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
|---|---|
| Power consumption (max) | 7 W |
| Input current | 0.3 A |
| AC input voltage | 24 V |
| Power over Ethernet (PoE) | Yes |
| Design | |
|---|---|
| LED indicators | Power |
| Reset button | Yes |
| Housing material | Plastic |
| Product colour | White |
| Placement | Pole |
| Antenna | |
|---|---|
| Polarization | Dual polarization |
| Antenna gain level (max) | 13 dBi |
| Antenna features | Integrated antenna |
| Antenna type | Internal |
| Performance | |
|---|---|
| Operating system installed | AirOS |
| Internal memory | 64 MB |
| Processor architecture | MIPS 74Kc |
| Processor frequency | 560 MHz |
| Processor model | Qualcomm Atheros |
| Built-in processor | Yes |
| Certificates | |
|---|---|
| Certification | CE, FCC, IC |
| Packaging content | |
|---|---|
| Mounting kit | Yes |
| Quantity per pack | 5 pc(s) |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
