Teltonika TSW110 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Blue, Grey
£47.99
Couldn't load pickup availability
- TSW110 is a layer 2 unmanaged switch, which is a simplified version of our earlier product – TSW100
- Possible to power up through the first LAN port
- It has five 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solution
- It offers a wide range of supported power supply voltages (9-30 V)
- Ideal for professional high bandwidth applications to provide reliable data connection
L2 UNMANAGED ETHERNET SWITCH
TSW110 is an unmanaged layer 2 Ethernet switch. This tiny but rugged professional device enables industrial high-bandwidth applications with a reliable data connection. It has five Gigabit Ethernet ports to connect equipment to the network and supports wide power supply voltages (9-30 V).
| Management features | |
|---|---|
| Switch type | Unmanaged |
| Ports & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| 10G support | No |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Data transmission | |
|---|---|
| MAC address table | 2000 entries |
| Switching capacity | 10 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9216 |
| Packet buffer memory | 0.128 MB |
| Design | |
|---|---|
| Product colour | Blue, Grey |
| Housing material | Aluminium |
| LED indicators | Yes |
| DIN rail mounting | Yes |
| International Protection (IP) code | IP30 |
| Power | |
|---|---|
| Power source | DC |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| DC input voltage | 30 V |
| Power consumption (typical) | 1.8 W |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
|---|---|
| Width | 100 mm |
| Depth | 85 mm |
| Height | 30 mm |
| Weight | 227 g |
| Packaging content | |
|---|---|
| Quick start guide | Yes |
| Packaging data | |
|---|---|
| Package type | Box |
