StarTech.com 4K HDMI 4-Port Video Splitter – 1x4 HDMI Splitter w/ Solid Aluminum Housing – 4K 30Hz
Spread the cost with Klarna, Clearpay, PayPal or FloatFrom 3 interest-free payments of £25.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- 4-PORT HDMI SPLITTER: Displays the same image with sound on 4 screens; Splits an HDMI video signal up to four HD/ 4K 30Hz & 7.1 CH audio; Support for 7.1 surround sound audio
- EDID EMULATION: 1x4 4K HDMI splitter automatically passes EDID between your video source and the first detected display ensuring native settings (such as resolution and refresh rate) are configured
- LONG REACH: Reach up to 16.4ft (5m) with a passive HDMI cable; For longer distances, active HDMI cables or HDMI extenders are available (sold separately) to use with this HDMI splitter for 4x TVs/projectors/monitors/displays
- EASY SETUP: No drivers required for this 1-input 4-output UHD HDMI 1.4 splitter box; Simply connect cables and power with the EDID switch set to Auto to get started; Wide screen monitor formats supported; HDMI/DVI compatible
- THE IT PRO'S CHOICE: Designed and built for IT Professionals, this HDMI Splitter with solid aluminum housing is backed for two years, including free lifetime 24/5 multi-lingual technical assistance
Split an HDMI audio/video source on four separate HDMI displays simultaneously, with support for resolutions up to 4K
The ST124HD4K 4-port 4K HDMI splitter lets you share four HDMI displays or projectors with an HDMI-enabled audio / video source devices, such as a computer, Blu-ray player or cable TV set-top box.
With support for Ultra HD (4K) the HDMI splitter ensures astonishing picture quality, four times the resolution of high-definition 1080p at 30 Hz. The 4K splitter is also backward compatible with previous HDMI revisions, supporting 1080p / 720p HDMI video resolution devices. Even if you don't require 4K video today, the ST124HD4K ensures you'll be ready to take advantage of tomorrow's display technology.
Save time while setting up your splitter with EDID emulation ensuring all of your native settings such as resolution and refresh rate are communicated between your video source and displays. EDID emulation maximizes compatibility with your 4K display, ensuring a convenient plug-and-play installation.
Constructed of solid aluminum, the HDMI splitter casing is heavy enough to prevent the unit from shifting or sliding around when you move the attached HDMI cables. Plus, the small footprint allows for seamless integration into any digital signage application.
The ST124HD4K is backed by a StarTech.com 2-year warranty, and free lifetime technical support.
The StarTech.com Advantage
Specifications
Ports & interfaces
| HDMI version | 1.4 |
|---|---|
| Video out | 4x HDMI |
| Video port type | HDMI |
| Video ports quantity | 4 |
Features
| Certification | CE, FCC, REACH |
|---|---|
| Supported video modes | 720p, 1080p, 2160p |
| LED indicators | Activity, Power |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA) |
| Maximum refresh rate | 30 Hz |
| Maximum operating distance | 5 m |
| Maximum resolution | 3840 x 2160 pixels |
| Housing material | Aluminium |
| Product colour | Black |
Show all 31 specificationsShow fewer specifications
Power
| Power consumption (typical) | 5 W |
|---|---|
| Output current | 1 A |
| Output voltage | 5 V |
| Input current | 0.35 A |
| AC input voltage | 100 - 240 V |
Weight & dimensions
| Weight | 280 g |
|---|---|
| Height | 12 mm |
| Depth | 140 mm |
| Width | 85 mm |
Packaging content
| AC adapter included | Yes |
|---|---|
| Included power plug types | AU, EU, NA, UK |
| Manual | Yes |
Operational conditions
| Operating relative humidity (H-H) | 5 - 90% |
|---|---|
| Storage temperature (T-T) | -10 - 80 °C |
| Operating temperature (T-T) | 0 - 70 °C |
Technical details
| Audio support | Yes |
|---|---|
| Supported audio channels | 7.1 |
| Compliance certificates | RoHS |
