SilverNet SIL 54424MP network switch Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
£1,164.99
Couldn't load pickup availability
- 24 x 10/100/1000Base-T RJ45 ports
- 4 x 10G SFP+ ports
- RJ45 supports auto MDI/MDI-X function
- Auto negotiation speed, half/full duplex
- Store and forward
- Max packet size: 10K bytes
- MAC address size: 16K
- IGMP Snooping
- SNMP Web Management Interface
- Port Mirroring
- Loop protection
- Link Layer Discovery Protocol (LLDP)
- Operating Temperature (0°C ~+50°C)
- Rack mountable
The SIL 54424MP is a Gigabit PoE+ Managed Switch. The switch is a fully managed layer 3 switch that provides stable and reliable Ethernet transmission.
The SIL 54424MP has 24 x 10/100/1000Base-T ports with 4 x 10G SFP+ and is powered using 240V AC.
The SIL 54424MP is perfect for network expansion. This switch offers configurable Layer 3 features like VLANs, PoE Scheduling, Static Routing, IGMP Snooping, and more. The SilverNet Commercial Gigabit + 10G Managed Switch provides excellent performance for evolving networks and is well-suited for VoIP phones, IP cameras, and wireless access points.
| Management features | |
|---|---|
| Configuring Location Settings (CLI) | Yes |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L3 |
| Switch type | Managed |
| Ports & interfaces | |
|---|---|
| Power connector | AC-in jack |
| Console port | DB9 |
| Fiber optic connector | LC |
| Combo SFP ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Network | |
|---|---|
| Number of VLANs | 256 |
| VLAN support | Yes |
| Auto-sensing | Yes |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Spanning tree protocol | Yes |
| Half duplex | Yes |
| Full duplex | Yes |
| Copper ethernet cabling technology | 10BASE-TX, 100BASE-TX, 1000BASE-TX |
| 10G support | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Data transmission | |
|---|---|
| Jumbo frames | 10000 |
| Jumbo frames support | Yes |
| Latency (10-100 Mbps) | 7 µs |
| Store-and-forward | Yes |
| Switching capacity | 128 Gbit/s |
| MAC address table | 16000 entries |
| Security | |
|---|---|
| Loop protection | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Multicast features | |
|---|---|
| Multicast support | Yes |
| Protocols | |
|---|---|
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Design | |
|---|---|
| Housing material | Metal |
| Product colour | Black |
| Form factor | 1U |
| Rack mounting | Yes |
| Performance | |
|---|---|
| Mean time between failures (MTBF) | 100819 h |
| Fanless | Yes |
| Firmware upgradeable | Yes |
| Power | |
|---|---|
| Power consumption (typical) | 24 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply included | Yes |
| Power source | AC |
| Power over Ethernet (PoE) | |
|---|---|
| Total Power over Ethernet (PoE) budget | 480 W |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet (PoE) ports quantity | 24 |
| Power over Ethernet (PoE) type supported | Active PoE |
| Power over Ethernet (PoE) | Yes |
| Other features | |
|---|---|
| Warranty period | 3 year(s) |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Weight & dimensions | |
|---|---|
| Weight | 4 kg |
| Height | 45 mm |
| Depth | 300 mm |
| Width | 400 mm |
| Packaging content | |
|---|---|
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Cables included | AC |
| Packaging data | |
|---|---|
| Package weight | 5.08 kg |
| Package height | 80 mm |
| Package depth | 495 mm |
| Package width | 393 mm |
| Package type | Box |
| Certificates | |
|---|---|
| Certification | FCC Part15 Class ACE-EMC/LVDRoHSEN61000-4-2 (ESD):LEVEL 4IEC 6100-4-2 (EFT):LEVEL 4IEC 6100-4-2 (Surge): LEVEL 4IEC 6100-4-2 (CS)：LEVEL 3IEC 61000-4-2(PFMP) : LEVEL 5EN61000-4-3 (RS):LEVEL 4IEC60068-2-27IEC60068-2-6IEC60068-2-31EN 609501, UL 60950 1, CSA C22.2 No.60950 1, UL 508 |
| Logistics data | |
|---|---|
| UK Trade Tariff code | 85176200 |
| Country of origin | United Kingdom |
