Opengear ACM7008-2-GLB gateway/controller 10, 100, 1000 Mbit/s
Couldn't load pickup availability
- 4-8 serial ports, out-of-band management of network and server devices
- 4 x USB 2.0 console ports, out-of-band management of network and server devices
For small IT deployments at edge locations, the Resilience Gateway provides secure remote access to your critical devices via Smart Out-of-Band management. An embedded, global 4G-LTE cellular modem offers an alternate path when the primary link is unavailable.
Connect devices directly to this small form-factor console server via 8 serial and 4 USB ports, providing always-on access to your remote networking equipment. Every model includes 4GB internal memory. Options include a 4-port GbE switch and models without the cellular modem.
Part of the Opengear Network Resilience Platform, the ACM7000 Resilience Gateway with Lighthouse management software and Failover to Cellular™ is used at small Retail locations, Bank branches/ATMs, regional offices, and at many other remote locations where business continuity is critical.
The ‘-GLB’ suffix indicates the unit ships with a 12V global power supply.
| Design | |
|---|---|
| Product colour | Black, Red |
| Mounting type | Rack mounting |
| LED indicators | Yes |
| Performance | |
|---|---|
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
| Number of processors installed | 1 |
| Internal memory type | DDR |
| Internal memory | 256 MB |
| Flash memory | 4032 MB |
| Protocols | |
|---|---|
| Management protocols | HTTPS, SSH, Nagios NSCA, NRPE, SNMP, TFTP & FTP |
| DHCP server | Yes |
| Network | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Dynamic DNS (DDNS) | Yes |
| Data transfer rate | 1000 Gbit/s |
| Security | |
|---|---|
| Authentication method | RADIUS, LDAP, PAP/CHAP |
| Firewall security | Yes |
| Ports & interfaces | |
|---|---|
| Interface | 8x RS-232 (RJ45), 4x USB, 2x DIO, 2x HVDO |
| USB 2.0 ports quantity | 4 |
| WAN connection | Ethernet (RJ-45) |
| Ethernet LAN (RJ-45) ports | 2 |
| Management features | |
|---|---|
| Syslog | Yes |
| Web-based management | Yes |
| Power | |
|---|---|
| Power consumption (typical) | 11.5 W |
| Input voltage | 110 - 240 V |
| Output voltage | 12 V |
| Weight & dimensions | |
|---|---|
| Weight | 600 g |
| Dimensions (WxDxH) | 130 x 120 x 35 mm |
| Packaging content | |
|---|---|
| AC adapter included | Yes |
| Quick installation guide | Yes |
| Cables included | AC |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 5 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Technical details | |
|---|---|
| Electromagnetic compatibility | EN 55022:2010, CISPR 22:2008, FCC Part 15 Subpart B:2015, ICES-003 Issue 5 (2014), AS/NZS CISPR 22:2009+A1:2010, EN 61000-3-2:2006/A2:2009, EN 61000-3-3:2008, EN 55024:2010, CISPR 24:2010, EN 61000-4-2:2009, EN 61000-4-3:2006+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8:2010, EN 61000-4-11:2004 |
