£3,810.99

Stock Available: 1
  • 420W internal power supply.
  • 1 slot for modular power supply (1+1 redundancy).
  • Any APS600Wv3, APS1200Wv2, or APS2000Wv2 can be used.
  • Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover.
  • Layer 3 feature set includes static, policy-based, and dynamic routing.
  • NETGEAR IGMP Plus™, NETGEAR AV OS, and Engage Controller speed up AV installations.
  • SMPTE ST 2110 Grand Master Clock and Boundary Clock for AES67 and ST2059-2 applications.
  • Multi-color LED on each physical port reflecting the profile color in the NETGEAR AV OS™ and Engage Controller.

POWER AND
THROUGHPUT

Edge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.

Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.

Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.

Sleek, Quiet Design
Less fan noise, and mounting ears included for rack mounting.

Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350

FOCUS ON THE EVENT
NOT FAN NOISE

Most models have quiet mode which greatly reduces fan noise.

DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.

MAXIMIZE PERFORMANCE WITH PRO WIFI ACCESS POINTS
Enable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.

Management features
Switch layer L3
Switch type Managed
Ports & interfaces
SFP28 ports quantity 4
Console port USB
Fiber optic connector SFP28
Fiber ports quantity 4
Basic switching RJ-45 Ethernet ports quantity 28
Network
Copper ethernet cabling technology 2.5GBASE-T, 10GBASE-T
10G support Yes
Data transmission
Jumbo frames support Yes
Switching capacity 400 Gbit/s
Security
IGMP snooping Yes
IGMP proxy Yes
Design
Product colour Black
Form factor 1U
Stackable Yes
Rack mounting Yes
Performance
Noise level 66 dB
Internal memory 4000 MB
Memory type DDR4-SDRAM
Power
Power supply included Yes
Power source AC
Power over Ethernet (PoE)
Total Power over Ethernet (PoE) budget 2520 W
Power over Ethernet (PoE) ports quantity 28
Power over Ethernet (PoE) type supported PoE++ (4PPoE)
Power over Ethernet (PoE) Yes
Weight & dimensions
Weight 7.38 kg
Height 43.2 mm
Depth 400 mm
Width 440 mm
Packaging content
Rack mount kit Yes
Manual Yes
Cables included AC, USB
