Neomounts FPMA-D750DWHITE Monitor arm 10-32" - gas spring - Topfix
Couldn't load pickup availability
- Maximum weight capacity: 8 kg
- Minimum screen size: 25.4 cm (10") Maximum screen size: 81.3 cm (32")
- Number of displays supported: 2
- Clamp/Grommet Mounting type: Desk
- Maximum VESA mount: 100 x 100 mm
- Gas spring Height adjustment Tilt adjustment
- Cable management
- Steel White
The Neomounts desk mount, model FPMA-D750DWHITE is a tilt-, swivel and rotatable desk mount for flat screens up to 32". This mount is a great choice for space saving placement on desks using a Topfix desk clamp or grommet.
Neomounts versatile tilt (170°), rotate (180°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is easily height adjustable from 0 to 31 centimetres using a gas spring. Depth adjustable from 0 to 47 centimetres. An innovative cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D750DWHITE has three pivot points and is suitable for screens up to 32" (81 cm). The weight capacity of this product is 2-8 kg each screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
| Mounting | |
|---|---|
| Maximum weight capacity | 8 kg |
| Minimum screen size | 25.4 cm (10") |
| Maximum screen size | 81.3 cm (32") |
| Mounting type | Desk |
| Maximum weight capacity (per display) | 8 kg |
| Mounting | Clamp/Grommet |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Panel mounting interface | 75 x 75 mm |
| Number of displays supported | 2 |
| Desk thickness (max) | 5 cm |
| Ergonomics | |
|---|---|
| Height adjustment | Yes |
| Height adjustment type | Gas spring |
| Height adjustment range | 200 - 500 mm |
| Adjustable depth | Yes |
| Depth adjustment range | 0 - 470 mm |
| Tilt adjustment | Yes |
| Tilt angle range | 0 - 170° |
| Swivelling | Yes |
| Swivel angle | 180° |
| Swivel angle range | 0 - 180° |
| Rotating | Yes |
| Angle of rotation | 180° |
| Number of pivot points | 3 |
| Cable management | Yes |
| Design | |
|---|---|
| Product colour | White |
| Housing material | Steel |
| Weight & dimensions | |
|---|---|
| Height | 500 mm |
| Weight | 4.3 kg |
| Packaging data | |
|---|---|
| Package width | 480 mm |
| Package depth | 400 mm |
| Package height | 123 mm |
| Package weight | 5.3 kg |
| Other features | |
|---|---|
| Minimum weight | 2 kg |
| Logistics data | |
|---|---|
| Master (outer) case width | 430 mm |
| Master (outer) case length | 495 mm |
| Master (outer) case height | 520 mm |
| Master (outer) case gross weight | 5.3 kg |
| Products per master (outer) case | 4 pc(s) |
| Products per pallet (EU) | 24 pc(s) |
| Master (outer) case net weight | 5.3 kg |
| Country of origin | China |
| Harmonized System (HS) code | 7326909890 |
