Lindy 9 Port HDMI Video Wall Scaler
Couldn't load pickup availability
- Scale a single HDMI input across up to 9 displays
- Create 13 different video wall layouts with a single unit
- Supports input resolutions of up to 3840x2160@30Hz
- Compose a video wall without any control software
- 2 year warranty
The 9 Port HDMI Video Wall Scaler allows a 4K HDMI input source to be arranged on 9 displays in a variety of configurations. The 4k input is divided up in to nine signals and sent to each display at 1080p creating the perfect digital signage or entertainment solution.
The unit features a HDMI input connection which allows one unique source to be used as well as HDMI audio extraction via the 3.5mm Stereo audio output.
This unit has been developed for use in installations which require maximum impact, such as retail, advertising and hospitality. Multiple video wall presets and adjustable picture options means the Scaler can deliver stunning video wall layouts.
Create even bigger Video Walls by combining two units together via HDMI for layouts up to 3x4 or 4x4.
| Features | |
|---|---|
| Control type | Buttons |
| Scaled resolutions | 1920 x 1080, 3840 x 2160 |
| Housing material | Metal |
| Product colour | Black |
| Video | |
|---|---|
| HDCP version | 1.4 |
| HDCP | Yes |
| Ports & interfaces | |
|---|---|
| RS-232 input ports | 1 |
| HDMI version | 1.4 |
| Number of HDMI outputs | 9 |
| HDMI in | 1 |
| Weight & dimensions | |
|---|---|
| Weight | 1.75 kg |
| Height | 35 mm |
| Depth | 185 mm |
| Width | 305 mm |
| Technical details | |
|---|---|
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA |
| Warranty period | 2 year(s) |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 10 - 85% |
| Storage temperature (T-T) | -10 - 80 °C |
| Operating temperature (T-T) | -10 - 45 °C |
| Certificates | |
|---|---|
| Certification | California 65 |
| Packaging data | |
|---|---|
| Package type | Box |
