Lindy 38519 video servers/encoder 3840 x 2160 pixels 60 fps
Couldn't load pickup availability
- Live streaming to popular services such as Facebook Live, YouTube, Twitch or custom servers
- Support stream standards RTSP/UDP, RTSP/TCP, RTP/UDP, TS/UDP, RTMP/RTMPS and SRT
- Supports 4K60 HDMI® with loop out, analog audio in and out ports
- OLED display, built-in Web GUI browser interface and APIs to control
The Lindy 4K60 HDMI® over IP Encoder is designed to stream AV content over IP networks using the H.265 or H.264 video compression standard,it supports resolutions up to 3840x2160@60Hz 4:4:4 8bit with a HDMI® loop out port for a local display.
Support RTSP/UDP, RTSP/TCP, RTP/UDP, TS/UDP, RTMP/RTMPS and SRT stream standards for the most popular services such as YouTube, Facebook Live, Twitch or custom-specified servers.
Mainstream and substreams can be configured with bit rates, simultaneous streaming and audio-only streaming is also supported.
This extender provides status LEDs and OLED display to show the IP address and have access to menu features, a web gui for the complete configuration and API commands to achieve flexible configurations including from third party control systems.
In addition the 1G Network port has PoE function to power the unit without a PSU.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
| Video | |
|---|---|
| Video compression formats | H.264, H.265 |
| Maximum frame rate | 60 fps |
| Maximum video resolution | 3840 x 2160 pixels |
| Design | |
|---|---|
| LED indicators | Yes |
| Housing material | Metal |
| Product colour | Black |
| Network | |
|---|---|
| Power over Ethernet (PoE) | Yes |
| Ports & interfaces | |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Audio connector type | 3.5 mm (1/8") |
| HDMI input ports quantity | 1 |
| Power | |
|---|---|
| Input voltage | 12 V |
| Weight & dimensions | |
|---|---|
| Weight | 190 g |
| Height | 30 mm |
| Depth | 130 mm |
| Width | 160 mm |
| Packaging data | |
|---|---|
| Package weight | 1.02 kg |
| Package height | 77 mm |
| Package depth | 181 mm |
| Package width | 213 mm |
| Operational conditions | |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Sustainability | |
|---|---|
| Compliance certificates | CE, UKCA, REACH, RoHS, Federal Communications Commission (FCC) |
