Lindy 200m Fibre Optic DisplayPort 1.2 & USB 2.0 KVM Extender
Couldn't load pickup availability
- Extends DisplayPort 1.4 and USB 2.0 signals up to 200m over a single cable
- Supports uncompressed DisplayPort signals up to 8K
- Supports the extension of up to four USB 2.0 devices
- Uses a single MPO/MTP Fibre Optic cable
Designed for highly demanding use cases the DisplayPort 1.4 & USB 2.0 KVM Extender is capable of supporting DisplayPort 1.4 resolutions up to Ultra HD 8K (7680x4320) at distances of up to 200m using a single MPO/MTP cable (OM3 12 Core Method A 1:1). Using fibre optic technology the Extender is capable of extending these Ultra HD video signals in real time without compression over long distances whilst also extending four USB 2.0 devices* such as a keyboard, mouse and USB drive. The Transmitter and Receiver units are electronically isolated from one another removing the risk of damage via ground loop.
Package Contents:
- Fibre Optic DisplayPort 1.4 & USB 2.0 KVM Extender (1 x Transmitter, 1 x Receiver)
- 2 x 5V 3A Multi-Country (EURO, UK, US & AUS) Power Supply
- LINDY Manual
| Features | |
|---|---|
| LED indicators | Yes |
| Material | Metal |
| Product colour | Black |
| Maximum digital resolution | 7680 x 4320 pixels |
| Cable types supported | Fiber |
| Maximum transfer distance | 200 m |
| Connectivity technology | Wired |
| Type | Transmitter & receiver |
| Transmitter | |
|---|---|
| Transmitter video port type | DisplayPort |
| Receiver | |
|---|---|
| Receiver local video port type | DisplayPort |
| Power | |
|---|---|
| Power consumption (receiver) (max) | 4 W |
| Power consumption (transmitter) (max) | 2.5 W |
| AC adapter output current | 3 A |
| AC adapter output voltage | 5 V |
| AC input voltage | 100 - 240 V |
| Weight & dimensions | |
|---|---|
| Receiver weight | 600 g |
| Receiver height | 3 cm |
| Receiver depth | 12 cm |
| Receiver width | 18 cm |
| Transmitter weight | 600 g |
| Transmitter height | 3 cm |
| Transmitter depth | 12 cm |
| Transmitter width | 18 cm |
| Packaging content | |
|---|---|
| Quick installation guide | Yes |
| Manual | Yes |
| AC adapter included | Yes |
| Operational conditions | |
|---|---|
| Storage temperature (T-T) | -20 - 75 °C |
| Operating temperature (T-T) | -10 - 50 °C |
| Technical details | |
|---|---|
| Maximum resolution | 7680 x 4320 pixels |
| Weight | 600 g |
