£2,009.99

Stock Available: 0
  • Intel® Xeon® E5 v4 E5-2609V4 1.7 GHz
  • 8 GB 2400 MHz DDR4-SDRAM 1 x 8
  • Tower (5U) 500 W

Need to increase your business productivity and improve operations while balancing your employees’ mobility, security and collaboration needs, all within your limited IT budget? HPE ProLiant ML350 Gen9 Server delivers a class-leading combination of performance, expandability, manageability, reliability and serviceability making it the choice for enterprise data centers, expanding SMBs and remote offices of larger businesses. ML350 Gen9 Server leverages the Intel® Xeon® E5-2600 v3 and v4 processors with up to 21% 1 performance gain, plus the latest HPE DDR4 SmartMemory offering up to 23% 2 performance increase.

Additional support for 12 Gb/s SAS, embedded 4x1GbE NIC with a broad range of graphics and compute options. Manage your HPE ProLiant Server in any IT environments by automating the most essential server lifecycle management tasks: deploy, update, monitor, and maintain with ease.

The ML350 Gen9 Server is ideal for enterprise IT infrastructure to mission critical applications.

Features

Performance with Unmatched Capacity and Reliability
- The HPE ProLiant ML350 Gen9 Server supports up to two Intel® Xeon® E5-2600 v3 or v4 processors offering improved performance.
- HPE Smart Array Controllers are designed to increase 12 Gb/s performance, data availability and storage capacity while providing the flexibility in choice of solutions that are simple to manage.
- Up to (24) DIMM slots to support HPE DDR4 SmartMemory 2400MHz, helping to prevent data loss and downtime with enhanced error handling while improving workload performance and power efficiency.

Availability, Expandability and Serviceability - A Winning Combination
- The HPE ProLiant ML350 Gen9 Server offers expandability with greater capacity with (8) to (24) LFF, (8) to (48) SFF drive options and increased I/O expansion.
- Large expansion capacity with (9) PCIe expansion slots, (8) USB ports, 5U Rack conversion, and Power Supply options.
- Embedded 4x1Gbe and choice of HPE PCIe standup 1GbE or 10GbE Adapters provide you flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.
- Wider GPU support (4) to boost performance in graphic and VDI applications for financial services, education, scientific research, and medical imaging.
- Worldwide availability, service and support with a complete range of Foundation Care offerings from installation to extended support.

Agile Infrastructure Management for Essential Administration
- The HPE ProLiant ML350 Gen9 Server provides powerful converged management capabilities for the infrastructure lifecycle with embedded server management for provisioning, updating and diagnostic support with HPE iLO.
- Configure in Unified Extensible Firmware Interface (UEFI) boot mode to provision local and remote servers with Intelligent Provisioning and Scripting Toolkits.
- Online personalized dashboard for converged infrastructure health monitoring and support management with HPE Insight Online.
- Optimize firmware and driver updates and reduce downtime with Smart Update, consisting of Smart Update Manager (SUM) and Service Pack for ProLiant (SPP).

Energy Efficiency by Design
- The HPE ProLiant ML350 Gen9 Server offers ENERGY STAR® qualified server configurations illustrate the HPE continued commitment to helping customers conserve energy and save money.
- Next generation high efficiency redundant HPE Flexible Slot Power Supplies provide up to 94% efficiency (Platinum Plus) and support for HPE’s Power Discovery Services.
- Improved ambient temperature standard with ASHRAE A3 and A4 3 helps you reduce cooling costs.

Processor
Conflict-Free processor Yes
Stepping R0
Thermal Monitoring Technologies Yes
Processor code SR2P1
Maximum internal memory supported by processor 1.54 TB
Execute Disable Bit Yes
Idle States Yes
Processor socket LGA 2011-v3
Processor lithography 14 nm
Processor threads 8
Processor operating modes 64-bit
Processor codename Broadwell
Tcase 74 °C
Memory types supported by processor DDR4-SDRAM
Memory clock speeds supported by processor 1600,1866 MHz
Maximum number of PCI Express lanes 40
Processor package size 45 x 52.5 mm
Supported instruction sets AVX 2.0
Scalability 2S
Embedded options available Yes
Maximum number of SMP processors 2
PCI Express configurations 1x4, 1x8, 1x16
Number of QPI links 2
Memory bandwidth supported by processor (max) 59.7 GB/s
ECC supported by processor Yes
Physical Address Extension (PAE) Yes
Processor series Intel Xeon E5-2600 v4
Bus type QPI
System bus rate 6.4 GT/s
Processor cache type Smart Cache
Thermal Design Power (TDP) 85 W
Number of processors installed 1
Memory channels supported by processor Quad
Motherboard chipset Intel C610
Processor cache 20 MB
Processor cores 8
Processor frequency 1.7 GHz
Processor model E5-2609V4
Processor family Intel® Xeon® E5 v4
Processor manufacturer Intel
Memory
Maximum internal memory 768 GB
Memory slots 24x DIMM
ECC Yes
Memory clock speed 2400 MHz
Memory layout (slots x size) 1 x 8 GB
Internal memory type DDR4-SDRAM
Internal memory 8 GB
Storage
Optical drive type No
RAID support Yes
Number of HDDs supported 8
HDD size 3.5"
HDD interface Serial ATA
Total storage capacity 0 GB
Maximum storage capacity 192 TB
Graphics
On-board graphics card model Not available
Network
LAN controller HP 331i
Ethernet LAN Yes
Ethernet interface type Gigabit Ethernet
Ports & interfaces
VGA (D-Sub) ports quantity 1
Serial ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 2
USB 2.0 ports quantity 4
Ethernet LAN (RJ-45) ports 4
Expansion slots
PCI Express slots version 3.0
Design
Chassis type Tower (5U)
Software
Compatible operating systems Microsoft Windows ServerCanonical UbuntuRed Hat Enterprise Linux (RHEL)SUSE Linux Enterprise Server (SLES)VMwareCitrix XenServer
Operating system installed No
Processor special features
Intel TSX-NI Yes
Intel Enhanced Halt State Yes
Intel® Secure Key Yes
Intel® OS Guard Yes
Intel Secure Key Technology version 1.00
Intel TSX-NI version 1.00
Intel® Hyper Threading Technology (Intel® HT Technology) No
Intel® Turbo Boost Technology No
Intel® AES New Instructions (Intel® AES-NI) Yes
Processor ARK ID 92990
Intel® Identity Protection Technology (Intel® IPT) No
Intel Flex Memory Access No
Intel Demand Based Switching Yes
Intel Identity Protection Technology version 0.00
CPU configuration (max) 2
Enhanced Intel SpeedStep Technology Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Trusted Execution Technology Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Power
Number of redundant power supplies installed 1
Power supply 500 W
General
Product family ProLiant
Product series ML
Sustainability
Sustainability certificates ENERGY STAR
Weight & dimensions
Weight 30 kg
Depth 769 mm
Height 464 mm
Width 219 mm
Other features
Graphics card G200
Graphics card family Matrox
