HPE ProLiant ML350 Gen9 E5-2620v4 2P 16GB-R P440ar 8SFF 500W PS Base server 0 GB Tower (5U) Intel® Xeon® E5 v4 2.1 GHz DDR4-SDRAM
Couldn't load pickup availability
- Intel® Xeon® E5 v4 E5-2620V4 2.1 GHz
- 16 GB 2400 MHz DDR4-SDRAM
- Tower (5U) 500 W
Need to increase your business productivity and improve operations while balancing your employees’ mobility, security and collaboration needs, all within your limited IT budget? HPE ProLiant ML350 Gen9 Server delivers a class-leading combination of performance, expandability, manageability, reliability and serviceability making it the choice for enterprise data centers, expanding SMBs and remote offices of larger businesses. ML350 Gen9 Server leverages the Intel® Xeon E5-2600 v3 and v4 processors with up to 21% 1 performance gain, plus the latest HPE DDR4 SmartMemory offering up to 23% 2 performance increase.
Additional support for 12 Gb/s SAS, embedded 4x1GbE NIC with a broad range of graphics and compute options. Manage your HPE ProLiant Server in any IT environments by automating the most essential server lifecycle management tasks: deploy, update, monitor, and maintain with ease.
The ML350 Gen9 Server is ideal for enterprise IT infrastructure to mission critical applications.
| Processor | |
|---|---|
| Conflict-Free processor | Yes |
| Stepping | R0 |
| Thermal Monitoring Technologies | Yes |
| Processor code | SR2R6 |
| Maximum internal memory supported by processor | 1.54 TB |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Processor socket | LGA 2011-v3 |
| Processor lithography | 14 nm |
| Processor threads | 16 |
| Processor operating modes | 64-bit |
| Processor codename | Broadwell |
| Tcase | 74 °C |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Maximum number of PCI Express lanes | 40 |
| Processor package size | 45 x 52.5 mm |
| Supported instruction sets | AVX 2.0 |
| Scalability | 2S |
| Embedded options available | Yes |
| Number of QPI links | 2 |
| Memory bandwidth supported by processor (max) | 68.3 GB/s |
| ECC supported by processor | Yes |
| Physical Address Extension (PAE) | Yes |
| Processor series | Intel Xeon E5-2600 v4 |
| Bus type | QPI |
| System bus rate | 8 GT/s |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 85 W |
| Number of processors installed | 1 |
| Memory channels supported by processor | Quad |
| Motherboard chipset | Intel C610 |
| Processor cache | 20 MB |
| Processor cores | 8 |
| Processor boost frequency | 3 GHz |
| Processor frequency | 2.1 GHz |
| Processor model | E5-2620V4 |
| Processor family | Intel® Xeon® E5 v4 |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Maximum internal memory | 768 GB |
| Memory slots | 24x DIMM |
| ECC | Yes |
| Memory clock speed | 2400 MHz |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Storage | |
|---|---|
| Supported storage drive interfaces | SAS, Serial ATA |
| Optical drive type | No |
| RAID support | Yes |
| Supported HDD sizes | 2.5" |
| Number of HDDs supported | 8 |
| HDD size | 2.5" |
| Total storage capacity | 0 GB |
| Maximum storage capacity | 96 TB |
| Network | |
|---|---|
| LAN controller | HP 331i |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 4 |
| Expansion slots | |
|---|---|
| PCI Express slots version | 3.0 |
| PCI-X slots | 9 |
| Design | |
|---|---|
| Chassis type | Tower (5U) |
| Software | |
|---|---|
| Compatible operating systems | Microsoft Windows ServerCanonical UbuntuRed Hat Enterprise Linux (RHEL)SUSE Linux Enterprise Server (SLES)VMwareCitrix XenServer |
| Operating system installed | No |
| Processor special features | |
|---|---|
| Intel TSX-NI | Yes |
| Intel Enhanced Halt State | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI version | 1.00 |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Processor ARK ID | 92986 |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel Flex Memory Access | No |
| Intel Demand Based Switching | Yes |
| Intel Identity Protection Technology version | 0.00 |
| CPU configuration (max) | 2 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Power | |
|---|---|
| Number of main power supplies | 1 |
| Power supply | 500 W |
| General | |
|---|---|
| Product family | ProLiant |
| Product series | ML |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 84714100 |
| Sustainability | |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
|---|---|
| Weight | 30 kg |
| Depth | 769 mm |
| Height | 464 mm |
| Width | 219 mm |
| Other features | |
|---|---|
| Graphics card family | Matrox |
