HPE ProLiant DL385 Gen10 Plus v2 7313 3.0GHz 16-core 1P 32GB-R MR416i-a 8SFF 800W PS EU Server
Couldn't load pickup availability
- AMD EPYC 7313 2.9 GHz
- 32 GB 3200 MHz DDR4-SDRAM 1 x 32
- Rack (2U) 800 W
Do you need a versatile server with built-in security and flexibility that addresses key applications such as Machine Learning or Deep Learning and Big Data Analytics? Building on HPE ProLiant as the intelligent foundation for hybrid cloud, the HPE ProLiant DL385 Gen10 Plus v2 server offers the 3rd Generation AMD EPYC™ Processors, delivering more performance compared to the prior generation. With up to 128 cores (per 2-socket configuration), 32 DIMMs for memory up to 3200 MHz, the HPE ProLiant DL385 Gen10 Plus v2 server delivers low cost virtual machines (VMs) with increased security. Equipped with PCIe Gen4 capabilities, the HPE ProLiant DL385 Gen10 Plus v2 server offers improved data transfer rates and higher networking speeds. Combined with supportability for graphic accelerators, a more advanced storage RAID solution and storage density, the HPE ProLiant DL385 Gen10 Plus v2 server is the ideal choice for ML/DL and Big Data Analytics.
What is new supporting point:
Enhanced storage management with Tri-mode storage controllers supporting NVMe/SAS/SATA drives.
Supports the new 3rd Generation AMD EPYC™ processors with 8-core and 16-core.
Powered by the 3rd Generation AMD EPYC™ processors with more compute performance compared to the previous generation.
| Processor | |
|---|---|
| Maximum number of SMP processors | 2 |
| Number of processors installed | 1 |
| Motherboard chipset | AMD SoC |
| Processor cache | 128 MB |
| Processor cores | 16 |
| Processor boost frequency | 3.7 GHz |
| Processor frequency | 2.9 GHz |
| Processor model | 7313 |
| Processor family | AMD EPYC |
| Processor manufacturer | AMD |
| Memory | |
|---|---|
| Maximum internal memory | 8.19 TB |
| Memory slots | 32x DIMM |
| ECC | Yes |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 32 GB |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 32 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Hot-Plug support | Yes |
| Supported RAID controllers | None |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
| RAID support | Yes |
| SSD interface | PCI Express 4.0 |
| Supported HDD sizes | 2.5" |
| Number of HDDs supported | 8 |
| HDD interface | SATA, Serial Attached SCSI (SAS) |
| Total storage capacity | 0 GB |
| Maximum storage capacity | 67.2 TB |
| Graphics | |
|---|---|
| Maximum graphics card memory | 16 MB |
| On-board graphics card | Yes |
| Network | |
|---|---|
| LAN controller | Broadcom 57416 |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| VGA (D-Sub) ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
| Design | |
|---|---|
| Rack mounting | Yes |
| Chassis type | Rack (2U) |
| Performance | |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Remote administration | iLO 5 ASIC |
| Software | |
|---|---|
| Compatible operating systems | Windows Server 2016Windows Server 2019 (Most Recent Version)VMware ESXi 6.7 U3VMware ESXi 7.0 U1/U2SUSE Linux Enterprise Server (SLES) 12 SP5SUSE Linux Enterprise Server (SLES) 15 SP2Red Hat Enterprise Linux (RHEL) 8.3Citrix Hypervisor 8.2Ubuntu 20.04 LTS |
| Operating system installed | No |
| Power | |
|---|---|
| Number of main power supplies | 1 |
| Power supply | 800 W |
| Redundant power supply (RPS) support | Yes |
| General | |
|---|---|
| Product family | ProLiant |
| Product series | DL |
| Sustainability | |
|---|---|
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
|---|---|
| Depth | 445.4 mm |
| Height | 87.5 mm |
| Width | 87.3 mm |
