£10,102.99

Stock Available: 0
  • Intel® Xeon® Gold 5218 2.3 GHz
  • 32 GB 2933 MHz DDR4-SDRAM 1 x 32
  • Rack (2U) 800 W

Where is your server bottlenecked...storage, compute, expansion? The HPE ProLiant DL380 Gen10 server delivers the latest in security, performance and expandability, backed by a comprehensive warranty. Standardize on the industry's most trusted compute platform. The HPE ProLiant DL380 Gen10 server is securely designed to reduce costs and complexity, featuring the First and Second Generation Intel Xeon Processor Scalable Family with up to a 60% performance gain [1] and 27% increase in cores [2], plus the HPE 2933 MT/s DDR4 SmartMemory supporting 3.0 TB. It supports 12 Gb/s SAS, and up to 20 NVMe drive plus a broad range of compute options. Intel Optane™ persistent memory 100 series for HPE offers unprecedented levels of performance for databases and analytic workloads. Run everything from the most basic to mission-critical applications and deploy with confidence.

What is new supporting point:
Defend applications and data before your server is built with the new HPE Trusted Supply Chain offering.
Supporting additional second generation Intel Xeon Scalable processor family offerings.
Increased Single-Width GPU Density with up to 7 NVIDIA Tesla T4 16GB Computational Accelerators or 7 Xilinx Alveo U50 Accelerators supported in a standard-depth 2U rack form factor
Networking Choice (NC) server models provide greater flexibility in the primary networking selection.
Intel Optane™ persistent memory 100 series for HPE offers the flexibility to deploy as dense memory or fast storage and enables per-socket memory capacity of up to 3.0 TB. [3]
iLO 5 security enhancements: Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor. HPE InfoSight provides cloud-based analytics to predict and prevent issues proactively.

Processor
Execute Disable Bit Yes
Embedded options available No
Maximum number of SMP processors 2
Number of processors installed 1
Motherboard chipset Intel® C621
Processor cache 22 MB
Processor cores 16
Processor boost frequency 3.9 GHz
Processor frequency 2.3 GHz
Processor model 5218
Processor generation 2nd Generation Intel® Xeon® Scalable
Processor family Intel® Xeon® Gold
Processor manufacturer Intel
Memory
Maximum internal memory 1.54 TB
Memory slots 24x DIMM
Memory clock speed 2933 MHz
Memory layout (slots x size) 1 x 32 GB
Memory ranking 2
Internal memory type DDR4-SDRAM
Internal memory 32 GB
Storage
Optical drive type No
Hot-Plug support Yes
Supported RAID controllers HPE MR416i-p Gen10 Plus x16 Lanes 4GB Cache NVMe/SAS 12G Controller
RAID levels 0, 1, 5, 6, 10, 50, 60
RAID support Yes
SSD interface PCI Express 4.0
Supported HDD sizes 2.5"
Number of HDDs supported 8
HDD interface SATA, Serial Attached SCSI (SAS)
Total storage capacity 0 GB
Maximum storage capacity 72 TB
Graphics
Maximum graphics card memory 16 MB
On-board graphics card Yes
Network
Ethernet LAN Yes
Ethernet interface type 10 Gigabit Ethernet
Ports & interfaces
DisplayPorts quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 5
Ethernet LAN (RJ-45) ports 2
Design
Rack mounting Yes
Chassis type Rack (2U)
Performance
Trusted Platform Module (TPM) Yes
Trusted Platform Module (TPM) version 2.0
Remote administration iLO 5 ASIC
Software
Compatible operating systems Windows Server 2022: Essentials, Standard, DatacenterWindows Server 2019: Essentials, Standard, DatacenterWindows Server 2016: Essentials, Standard, DatacenterWindows Server 2012 R2: Essentials, Standard, DatacenterMicrosoft Hyper-V Server: 2012 R2, 2016 & 2019VMware vSphere 6.0 U3, 6.5 U2 through U.3 & 6.7 U1 through U3, 7.0ClearOS: 7.6; ClearVM: 2.0Red Hat Enterprise Linux (RHEL) 7.6 w/ Kbase**, 8.0SUSE Linux Enterprise Server (SLES) 12 SP3, 15 (includes Xen)
Operating system installed No
Processor special features
Enhanced Intel SpeedStep Technology Yes
Intel Virtualization Technology for Directed I/O (VT-d) Yes
Intel Trusted Execution Technology Yes
Intel VT-x with Extended Page Tables (EPT) Yes
Intel 64 Yes
Intel Virtualization Technology (VT-x) Yes
Power
Number of main power supplies 1
Power supply 800 W
Redundant power supply (RPS) support Yes
General
Product family ProLiant
Product series DL
Sustainability
Sustainability certificates ENERGY STAR
Weight & dimensions
Weight 14.8 kg
Depth 730.3 mm
Height 87.4 mm
Width 445.5 mm
