HPE ProLiant DL360 Gen10 Plus 5315Y 3.2GHz 8-core 1P 32GB-R MR416i-a NC 8SFF 800W PS Server
Couldn't load pickup availability
- Intel Xeon Silver 5315Y 3.2 GHz
- 32 GB 3200 MHz DDR4-SDRAM 1 x 32
- Rack (1U) 800 W
Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency while backed by a comprehensive warranty, the HPE ProLiant DL360 Gen10 Plus server is ideal for IT infrastructure, either physical, virtual, or containerized. Powered by 3rd Generation Intel Xeon Scalable Processors, delivering up to 40 cores, 3200 MT/s memory, and introducing PCIe Gen4 and Intel Software Guard Extension (SGX) support to the dual-socket segment, the HPE ProLiant DL360 Gen10 Plus server delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at any cost.
What is new supporting point:
Choice of storage backplanes and cages, offering diverse bay counts, protocols, and bandwidth that enable customers to design their server storage for their precise needs.
Support for industry-standard OCP 3.0 Network Adapters, enhancing customer choice.
Slot-less HW RAID protected M.2 boot solution, providing peace-of-mind O/S deployment while saving invaluable slots and storage bays.
64 PCIe Gen4 lanes, resulting in more devices, improved bandwidth and augmented balanced I/O capabilities.
Enhanced storage capabilities with Tri-mode controllers supporting NVMe/SAS/SATA drives, allowing customers to select the ideal media type and mix for their exact application.
Supports 3rd Generation Intel Xeon Scalable Processors for enhanced compute performance.
| Processor | |
|---|---|
| Processor cache type | L3 |
| Number of processors installed | 1 |
| Motherboard chipset | Intel C621A |
| Processor cache | 12 MB |
| Processor cores | 8 |
| Processor boost frequency | 3.6 GHz |
| Processor frequency | 3.2 GHz |
| Processor model | 5315Y |
| Processor family | Intel Xeon Silver |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 32 GB |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 32 GB |
| Storage | |
|---|---|
| Optical drive type | No |
| Supported RAID controllers | HPE MR416i-a Gen10 Plus x16 Lanes 4GB Cache NVMe/SAS 12G Controller |
| RAID support | Yes |
| SSD interface | PCI Express 4.0 |
| Network | |
|---|---|
| LAN controller | Broadcom BCM57416 |
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ports & interfaces | |
|---|---|
| Expansion slots | 2 PCIe Gen4: 1 x16 FH, 1 x16 LP |
| Ethernet LAN (RJ-45) ports | 2 |
| Expansion slots | |
|---|---|
| PCI Express x16 slots | 2 |
| Design | |
|---|---|
| Product colour | Silver |
| Chassis type | Rack (1U) |
| Performance | |
|---|---|
| Management platform | Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional - HPE iLO Advanced, and HPE OneView Advanced |
| Trusted Platform Module (TPM) | Yes |
| Performance management | HPE iLO 5 |
| Software | |
|---|---|
| Operating system installed | No |
| Power | |
|---|---|
| Number of main power supplies | 1 |
| Power supply | 800 W |
| Power supply type | 1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit |
| Redundant power supply (RPS) support | No |
| Weight & dimensions | |
|---|---|
| Depth | 434.6 mm |
| Height | 769.6 mm |
| Width | 42.9 mm |
| Other features | |
|---|---|
| Standard fans | 7x High Performance fans |
| Storage drive type | None ship standard, 8 SFF supported |
| Security features | UEFI Secure Boot and Secure Start support Intel Software Guard Extensions (SGX) support Immutable Silicon Root of Trust Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits |
| Number of processors supported | 1 |
