£10,765.99

Stock Available: 0
  • Intel Xeon Silver 4310 2.1 GHz
  • 32 GB 3200 MHz DDR4-SDRAM 1 x 32
  • Rack (1U) 800 W

Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable for diverse workloads and environments, the compact 1U HPE ProLiant DL360 Gen10 Plus server delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency while backed by a comprehensive warranty, the HPE ProLiant DL360 Gen10 Plus server is ideal for IT infrastructure, either physical, virtual, or containerized. Powered by 3rd Generation Intel Xeon Scalable Processors, delivering up to 40 cores, 3200 MT/s memory, and introducing PCIe Gen4 and Intel Software Guard Extension (SGX) support to the dual-socket segment, the HPE ProLiant DL360 Gen10 Plus server delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at any cost.

What is new supporting point:
Support for industry-standard OCP 3.0 Network Adapters, enhancing customer choice.
Slot-less HW RAID protected M.2 boot solution, providing peace-of-mind O/S deployment while saving invaluable slots and storage bays.
Choice of storage backplanes and cages, offering diverse bay counts, protocols, and bandwidth that enable customers to design their server storage for their precise needs.
Enhanced storage capabilities with Tri-mode controllers supporting NVMe/SAS/SATA drives, allowing customers to select the ideal media type and mix for their exact application.
64 PCIe Gen4 lanes, resulting in more devices, improved bandwidth and augmented balanced I/O capabilities.
Supports 3rd Generation Intel Xeon Scalable Processors for enhanced compute performance.

Processor
Maximum number of SMP processors 2
Processor cache type L3
Number of processors installed 1
Motherboard chipset Intel C621A
Processor cache 18 MB
Processor cores 12
Processor boost frequency 3.3 GHz
Processor frequency 2.1 GHz
Processor model 4310
Processor generation 3rd Generation Intel® Xeon® Scalable
Processor family Intel Xeon Silver
Processor manufacturer Intel
Memory
Memory slots 32x DIMM
Memory clock speed 3200 MHz
Memory layout (slots x size) 1 x 32 GB
Internal memory type DDR4-SDRAM
Internal memory 32 GB
Storage
Optical drive type No
Supported RAID controllers HPE MR416i-a Gen10 Plus x16 Lanes 4GB Cache NVMe/SAS 12G Controller
RAID support Yes
SSD interface PCI Express 4.0
Supported HDD sizes 2.5"
Number of HDDs supported 8
Total storage capacity 0 GB
Maximum storage capacity 153.6 TB
Network
LAN controller Broadcom BCM57416
Ethernet LAN Yes
Ethernet interface type 10 Gigabit Ethernet
Ports & interfaces
Expansion slots 2 PCIe Gen4: 1 x16 FH, 1 x16 LP
VGA (D-Sub) ports quantity 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 3
Ethernet LAN (RJ-45) ports 2
Expansion slots
PCI Express x16 slots 2
Design
Redundant fans support Yes
Rack mounting Yes
Chassis type Rack (1U)
Performance
Management platform Included - HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional - HPE iLO Advanced, and HPE OneView Advanced
Trusted Platform Module (TPM) Yes
Trusted Platform Module (TPM) version 2.0
Remote administration iLO 5 ASIC
Software
Compatible operating systems Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Enterprise Linux 7.9, Red Hat Enterprise Linux 8.2, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise Server 15 SP2, VMware vSphere 6.7 (ESXi) Update 3
Operating system installed No
Power
Number of main power supplies 1
Power supply 800 W
Power supply type 1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
General
Product family ProLiant
Product series DL
Weight & dimensions
Weight 13 kg
Depth 707 mm
Height 42.9 mm
Width 434.6 mm
Other features
Standard fans 7x High Performance fans
Storage drive type None ship standard, 8 SFF supported
Security features UEFI Secure Boot and Secure Start support Intel Software Guard Extensions (SGX) support Immutable Silicon Root of Trust Optional Trusted Supply Chain, iLO Security modes, TPM, Chassis Intrusion detection and Bezel Locking kits
Number of processors supported 1
