£12,805.99

Stock Available: 0
  • Intel® Xeon® Gold 5416S 2 GHz
  • 32 GB 4800 MHz DDR5-SDRAM 1 x 32
  • Rack (2U) 500 W

Are you looking to run edge AI workloads like Computer Vision that need GPU accelerators or distributed data solutions that require expandable storage? The HPE ProLiant DL320 Gen11 is a 1U 1P server with a unique compact design and workload-driven modular design that is purpose-built for edge computing delivering exceptional performance at 1P economics and an excellent choice for both virtualized and containerized workloads. Powered by 4th and 5th Gen Intel Xeon Scalable Processors with up to 60 cores, 270W, increased memory capability (up to 2 TB 5600 MT/s), and high-speed PCIe Gen5 supporting up to four single-wide GPUs (or two double-wide), the HPE ProLiant DL320 Gen11 server is a perfect low-cost, 1U 1P, performance solution. The HPE ProLiant Gen11 servers are engineered to optimize IT at the edge with a cloud operating experience, built-in security, and optimized performance for workloads to drive your business forward.

What is new supporting point:
Support for up to 4 Single Wide or 2 Double Wide GPUs in the front cage with the GPU CTO server.
Powered by the 4th and 5th Gen Intel Xeon Scalable Processors with next-generation 5nm technology that supports up to 60 cores at 270W and 16 DIMMs of DDR5 memory up to 5600 MT/s.
16 DIMMs per processor for up to 2 TB total DDR5 memory with increased memory bandwidth and performance, and lower power requirements.
Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 2x16 PCIe Gen5 and 1 OCP3.0 slots.
Includes the new HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly, from anywhere.
Supports hot-pluggable or internal, high-availability RAID1 NVMe M.2 boot options.

Processor
Number of processors installed 1
Motherboard chipset Intel C741
Processor cache 30 MB
Processor cores 16
Processor boost frequency 4 GHz
Processor frequency 2 GHz
Processor model 5416S
Processor family Intel® Xeon® Gold
Processor manufacturer Intel
Memory
Maximum internal memory 2.05 TB
Memory slots 16x DIMM
ECC Yes
Memory clock speed 4800 MHz
Memory layout (slots x size) 1 x 32 GB
Internal memory type DDR5-SDRAM
Internal memory 32 GB
Storage
Optical drive type No
Hot-Plug support Yes
Supported RAID controllers None
RAID levels 0, 1, 5, 6, 10, 50, 60
RAID support Yes
Number of SSDs supported 8
Supported SSD sizes 2.5"
SSD interface PCI Express 4.0
NVMe Yes
Supported HDD sizes 2.5"
Number of HDDs supported 8
HDD interface SATA, Serial Attached SCSI (SAS)
Total storage capacity 0 GB
Maximum storage capacity 153 TB
Network
Ethernet LAN Yes
Ethernet interface type Gigabit Ethernet
Ports & interfaces
SFP/SFP+ slots quantity 3
Ethernet LAN (RJ-45) ports 2
Design
Rack mounting Yes
Chassis type Rack (2U)
Performance
Trusted Platform Module (TPM) Yes
Trusted Platform Module (TPM) version 2.0
Remote administration iLO 6 ASIC
Software
Compatible operating systems Microsoft Windows ServerVMware ESXiRed Hat Enterprise Linux (RHEL)SUSE Linux Enterprise Server (SLES)Canonical UbuntuOracle Linux and Oracle VMCitrixCommunity Enterprise Linux (CentOS, Alma Linux, Rocky Linux)
Operating system installed No
Power
Number of main power supplies 1
Power supply 500 W
Redundant power supply (RPS) support Yes
General
Product family ProLiant
Product series DL
