HPE ProLiant Compute DL340 Gen12 6505P 2.2GHz 12c 1P 2x32GB-R 8SFF MR408i-o 2x1000W PS EU Server
Spread the cost with Klarna, Float or SnapFrom 3 interest-free payments of £2,375.99 See options
Credit subject to status. 18+, UK residents only. See each provider for terms.
Out of stock
FREE delivery
Express £9.99
Couldn't load pickup availability
- 14-day returns Details
- UK manufacturer warranty Details
- Price Match Promise Details
- Rated 4.9/5 by customers on Trustpilot & Feefo Read reviews
Available now
Overview
- Intel® Xeon® 2.2 GHz
- 64 GB 6400 MHz DDR5-SDRAM 2 x 32
- Rack (2U) 1000 W
Do you need a 2U single-socket server that highlights reduced power consumption and better thermals for your data and storage-centric workloads that need more PCIe lanes? The HPE ProLiant Compute DL340 Gen12 is a 2U 1P server that offers three CTO chassis that support SFF, LFF, and GPU configurations. The 3-box modular front design enhances the configuration flexibility. Due to the configuration flexibility and the energy efficiency (reduced power consumption due to better thermals within a 2U chassis), the HPE ProLiant Compute DL340 Gen12 server is ideal for customers that have a requirement for Infrastructure-as-a-Service (IaaS), Platform-as-a Service (PaaS), and Software-as-a-Service (SaaS) workloads. Powered by Intel Xeon 6 processors with up to 144 cores, increased memory capability (up to 4 TB), and high-speed PCIe Gen5, the HPE ProLiant Compute DL340 Gen12 server is a great 2U single-socket performance solution driving better datacenter efficiency.
What is new supporting point:
Powered by Intel Xeon 6 processors; Up to 144 cores per socket. Increased memory bandwidth to 6400 MT/s, up to 4 TB DDR5 memory capacity.
Specifications
Processor
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel® Xeon® |
| Processor frequency | 2.2 GHz |
| Processor cache | 48 MB |
| Number of processors installed | 1 |
| Processor cache type | L3 |
Memory
| Internal memory | 64 GB |
|---|---|
| Internal memory type | DDR5-SDRAM |
| Memory layout (slots x size) | 2 x 32 GB |
| Memory clock speed | 6400 MHz |
Show all 26 specificationsShow fewer specifications
Storage
| Supported RAID controllers | HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller |
|---|---|
| Optical drive type | No |
Network
| Ethernet interface type | Gigabit Ethernet |
|---|---|
| Ethernet LAN | Yes |
| LAN controller | Broadcom BCM5719 |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 4 |
|---|---|
| Expansion slots | Up to 6 PCIe Gen5, and 2 OCP 3.0, for detailed descriptions reference the QuickSpecs |
Design
| Chassis type | Rack (2U) |
|---|
Performance
| Management platform | HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (optional subscription available). Refer to theiLO 7 User Guide |
|---|
Power
| Power supply type | 2x HPE 1000W M-CRPS Titanium Hot Plug Power Supply Kit |
|---|---|
| Power supply | 1000 W |
| Number of main power supplies | 2 |
Other features
| Number of processors supported | 1 |
|---|---|
| Security features | For full security features refer to the QuickSpecs |
| Storage drive type | None ship standard, 8 SFF supported |
| Standard fans | 6x Standard Fans |
