Hewlett Packard Enterprise
£176.99
Stock Available: 0
  • 2.4 GHz 574 Mbit/s
  • 5 GHz 1200 Mbit/s
  • Maximum data transfer rate: 1200 Mbit/s
  • IEEE 802.11ax
  • OWE, WPA2, WPA3
  • Power over Ethernet (PoE)
  • Antennas quantity: 2 Internal

The HPE Networking Instant On Access Points AP22D is an SMB-focused Wi-Fi CERTIFIED 6™ access point that provides reliable wired and wireless connectivity over a 2.5 GbE uplink port with a minimal device footprint. This access point can reduce device clutter while powering downlink devices such as IP Phones or receipt printers with 2x 15W of PoE (802.3af) and supporting 75+ wireless devices over 802.11ax Wi-Fi 6 with an aggregate wireless throughput of 1.7 Gbps. Easily manage the Instant On AP22D with the Instant On mobile app or portal to create guest and employee networks, govern access control lists, and set PoE schedules to customize power use. Make the most of your limited space in your small business by mounting the Instant On AP22D to a desk or wall with included mounting kits.

What is new supporting point:
Wi-Fi CERTIFIED 6™ wireless access point, with 2.5 GbE uplink port
2.5 GbE uplink port provides up to 2x more bandwidth than 1 GbE ports without the need for new Cat5/6(a) cables to be installed.
Four 1 GbE downlink ports that supply up to 2x 15W of PoE (802.3af).
Up to 1.7 Gbps aggregate wireless throughput.

Features
MIMO type Multi User MIMO
MIMO Yes
Number of users 75 user(s)
Cabling technology 10/100/1000Base-T(X)
Networking standards IEEE 802.11ax
Ethernet LAN data rates 1000,2500 Mbit/s
Maximum data transfer rate (5 GHz) 1200 Mbit/s
Maximum data transfer rate (2.4 GHz) 574 Mbit/s
Maximum data transfer rate 1200 Mbit/s
5 GHz Yes
6 GHz No
2.4 GHz Yes
Security
Security algorithms OWE, WPA2, WPA3
Ports & interfaces
DC-in jack Yes
USB 2.0 ports quantity 1
Ethernet LAN (RJ-45) ports 5
Power
Power consumption (max) 51 W
DC voltage range 48 V
Power over Ethernet (PoE) Yes
Design
Reset button Yes
Cable lock slot type Kensington
Cable lock slot Yes
Product colour White
Placement Desk, Wall
Antenna
Antenna gain level (max) 5.4 dBi
Antennas quantity 2
Antenna direction type Semi-directional
Antenna type Internal
Certificates
Certification None
Weight & dimensions
Weight 360 g
Height 150 mm
Depth 47 mm
Width 86 mm
Operational conditions
Operating temperature (T-T) 0 - 40 °C
