Overview

  • Managed L3
  • Basic switching RJ-45 Ethernet ports quantity: 48 Console port: RJ-45
  • 10G support
  • Switching capacity: 176 Gbit/s
  • Rack mounting Stackable
  • AC Power supply included Power over Ethernet (PoE)

The HPE Networking Comware Switch Series 5150 EI is a family of stackable L3 access switches powered by HPE Comware OS delivering scalability and resiliency at a modest TCO for small, medium, and large enterprise campus networks. With 8, 24, and 48 gigabit ports, options for mixed copper and fiber connectivity, and up to 30 watts of 802.3at PoE per port this flexible series is ready to connect your edge clients, servers, and IoT devices. Built-in 10 GbE uplinks and Intelligent Resilient Fabric (IRF) stacking up to 9-members adds scale, resiliency, and simplification to your access network, enabling network operators to manage the whole stack as a single logical switch. Network visibility, management, and operation tools for this series include standard CLI and the Smart Management Center (SmartMC), embedded and ready to use at no additional cost. The series integrates with HPE Aruba Networking IMC, delivering a centralized point of control for your entire network.

What is new supporting point:
Family of stackable L3 access switches with 1 GbE downlinks, 10 GbE uplinks, and support OSPF, EIGRP, ISIS, RIP and routed access. PoE-enabled models deliver up to 30 watts of 802.3at power per port.
8, 24, and 48 port configurations available, supporting up to 176 Gbps of switching capacity and 130 Mpps of forwarding throughput. 24-port fiber option with redundant, dual modular power supplies.
Up to 432 ports of scalability with Intelligent Resilient Fabric (IRF) stacking up to 9-members for link and device aggregation across your network, enhancing redundancy and resource usage.
Standard CLI and Smart Management Center (SmartMC) embedded and ready to use, delivering network visibility, management, and operations at no additional cost.
Energy Efficient Ethernet and energy-saving green design initiatives support your sustainability efforts by automatically reducing power to idle ports and powering down unused ports.

Specifications

Management features

Switch typeManaged
Switch layerL3

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP+ module slots quantity4
Console portRJ-45
Show all 36 specificationsShow fewer specifications

Network

10G supportYes

Data transmission

Switching capacity176 Gbit/s
Throughput131 Mpps
Latency (1 Gbps)5 µs
Latency (10 Gbps)3 µs
Packet buffer memory1.5 MB

Protocols

IPv6 FIB entries256

Design

Rack mountingYes
StackableYes
Product colourBlack

Performance

Physical stacking (units)9
Processor manufacturerARM
Built-in processorYes
Processor frequency1200 MHz
Memory typeSDRAM / Flash
Internal memory2048 MB
Flash memory1024 MB

Power

Power sourceAC
Power supply includedYes
AC input voltage90 - 290 V
Power consumption (max)969 W
Power consumption noteIdle: Single AC: 35W Full Load: Single AC: 969W (PoE 770W)

Power over Ethernet (PoE)

Power over Ethernet (PoE)Yes
Total Power over Ethernet (PoE) budget770 W

Other features

Latency1GE: < 5 µs; 10GE: < 3 µs
Performance managementIMC - Intelligent Management Center; Command-line interface; SNMP manager; SmartMC GUI
Memory and processorCPU: Arm 1.2 GHz Dual Core 2 GB SDRAM, 1 GB Flash, 1.5 MB packet buffer
Port speed rating48p 10M/100M/1G PoE+ 4p SFP+ 1G/10G

Operational conditions

Operating temperature (T-T)-5 - 45 °C

Weight & dimensions

Width3.6 mm
