HPE Networking Comware Switch 24p 10/100/1000BASE-T 4p SFP+ 1 Exp 2 PS Slot 5520HI
Couldn't load pickup availability
- Managed L3
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 24
- 10G support
- Switching capacity: 288 Gbit/s
- Rack mounting Stackable
- Power supply included
The HPE Networking Comware Switch Series 5520 HI delivers superior performance, high availability and manageability with advanced features at the access and aggregation layer of medium and large enterprise networks. These switches deliver faster performance and advanced L3 features with support for larger ARP/MAC tables and Longest Prefix Match (LPM). VXLAN and EVPN enable greater scalability. Support for Virtual Router Redundancy Protocol (VRRP), Equal-Cost Multipath (ECMP) and Bi-directional Forwarding Detection (BFD) provide resiliency. Intelligent Resilient framework (IRF) ensures high availability. Support for IPv4/IPv6, OpenFlow, and MPLS/VPLS features for investment protection with an easy transition from IPv4 to IPv6 networks. These switches also include SmartMC at no additional cost, and when combined with Intelligent Management Center (IMC), it provides both embedded network management and enhanced network visibility.
What is new supporting point:
Larger MAC tables (up to 64K), Longest Prefix Match (LPM), switching capacity of up to 336 Gbps and throughput of upto 180 Mpps enable faster switching.
Virtual Extensible LAN (VXLAN) and Ethernet VPN (EVPN) enable both isolation and greater scalability of L2/L3 overlay services and multicast.
Smart Management Center (SmartMC) provides centralized network management and maintains dispersed network edge devices at no additional cost.
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to address common programming issues, easing concerns about 'made in China' products.
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L3 |
| Quality of Service (QoS) support | Yes |
| Ports & interfaces | |
|---|---|
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 4 |
| Network | |
|---|---|
| 10G support | Yes |
| Data transmission | |
|---|---|
| Switching capacity | 288 Gbit/s |
| Throughput | 180 Mpps |
| Latency (1 Gbps) | 5 µs |
| Latency (10 Gbps) | 3 µs |
| Packet buffer memory | 4 MB |
| Design | |
|---|---|
| Rack mounting | Yes |
| Stackable | Yes |
| Number of fans | 2 fan(s) |
| Performance | |
|---|---|
| Physical stacking (units) | 9 |
| Memory type | DDR4-SDRAM |
| Internal memory | 2048 MB |
| Flash memory | 512 MB |
| Power | |
|---|---|
| Power supply included | Yes |
| AC input voltage | 90 - 264 V |
| DC input voltage | 36 - 72 V |
| Power consumption (max) | 150 W |
| Power consumption note | 150W (maximum) |
| Power over Ethernet (PoE) | |
|---|---|
| Power over Ethernet (PoE) | No |
| Other features | |
|---|---|
| Latency | 1000 Mb Latency: < 5 µs 10 Gbps Latency: < 3 µs |
| Performance management | IMC - Intelligent Management Center; Command-line interface; SNMP manager |
| Memory and processor | 2 GB SDRAM; Packet buffer size: 4 MB, 512 MB flash |
| I/O ports | (16) 10/100/1000BASE-T RJ-45 ports (8) dual-personality ports - 10/100/1000BASE-T RJ-45 or 100/1000BASE-X Combo Ports; Duplex: Ports 1-24 support 10BASE-T/100BASE-TX, 1000BASE-T (full only), (4) SFP+ 1/10GbE ports, (1) port expansion module slot. |
| Operational conditions | |
|---|---|
| Heat dissipation | 324 BTU/h |
| Weight & dimensions | |
|---|---|
| Width | 440 mm |
| Depth | 360 mm |
| Height | 43.6 mm |
| Weight | 6.7 kg |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 85176990 |
