HPE Networking Comware Switch 24 10/100/1000BASE-T 4 10G/1G BASE-X SFP+ 1 Exp 2 Fan Tray 2 PS 5520HI
HPE Networking Comware Switch 24 10/100/1000BASE-T 4 10G/1G BASE-X SFP+ 1 Exp 2 Fan Tray 2 PS 5520HI
HPE Networking Comware Switch 24 10/100/1000BASE-T 4 10G/1G BASE-X SFP+ 1 Exp 2 Fan Tray 2 PS 5520HI
HPE Networking Comware Switch 24 10/100/1000BASE-T 4 10G/1G BASE-X SFP+ 1 Exp 2 Fan Tray 2 PS 5520HI

HPE Networking Comware Switch 24 10/100/1000BASE-T 4 10G/1G BASE-X SFP+ 1 Exp 2 Fan Tray 2 PS 5520HI

Hewlett Packard Enterprise
£7,191.99
Stock Available: 0
  • Managed
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • 10G support
  • MAC address table: 32768 entries Switching capacity: 288 Gbit/s
  • 1U Rack mounting Stackable
  • AC/DC Power over Ethernet (PoE)

The HPE Networking Comware Switch Series 5520 HI delivers superior performance, high availability and manageability with advanced features at the access and aggregation layer of medium and large enterprise networks. These switches deliver faster performance and advanced L3 features with support for larger ARP/MAC tables and Longest Prefix Match (LPM). VXLAN and EVPN enable greater scalability. Support for Virtual Router Redundancy Protocol (VRRP), Equal-Cost Multipath (ECMP) and Bi-directional Forwarding Detection (BFD) provide resiliency. Intelligent Resilient framework (IRF) ensures high availability. Support for IPv4/IPv6, OpenFlow, and MPLS/VPLS features for investment protection with an easy transition from IPv4 to IPv6 networks. These switches also include SmartMC at no additional cost, and when combined with Intelligent Management Center (IMC), it provides both embedded network management and enhanced network visibility.

What is new supporting point:
New made in USA TAA-compliant SKUs offer heightened security via manual and automated source code analysis to address common programming issues, easing concerns about 'made in China' products.
Virtual Extensible LAN (VXLAN) and Ethernet VPN (EVPN) enable both isolation and greater scalability of L2/L3 overlay services and multicast.
Larger MAC tables (up to 64K), Longest Prefix Match (LPM), switching capacity of up to 336 Gbps and throughput of upto 180 Mpps enable faster switching.
Smart Management Center (SmartMC) provides centralized network management and maintains dispersed network edge devices at no additional cost.

Management features
Switch type Managed
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity 4
USB 2.0 ports quantity 1
Network
10G support Yes
Data transmission
MAC address table 32768 entries
Switching capacity 288 Gbit/s
Throughput 180 Mpps
Latency (1 Gbps) 5 µs
Latency (10 Gbps) 3 µs
Packet buffer memory 4 MB
Design
Rack mounting Yes
Stackable Yes
Form factor 1U
Product colour Black
Performance
Physical stacking (units) 9
Internal memory 2048 MB
Flash memory 512 MB
Power
Power source AC/DC
AC input voltage 90 - 264 V
DC input voltage 36 - 72 V
Power consumption (max) 1110 W
Power consumption note 1110W (maximum)
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Total Power over Ethernet (PoE) budget 720 W
Other features
Latency 1000 Mb Latency: < 5 µs 10 Gbps Latency: < 3 µs
Performance management IMC - Intelligent Management Center; Command-line interface; SNMP manager
Memory and processor 2 GB SDRAM; Packet buffer size: 4 MB, 512 MB flash
I/O ports (24) RJ-45 autosensing 100/1000 BASE-T ports( PoE+); Duplex: Ports 1-24 support 10BASE-T/100BASE-TX, 1000BASE-T (full only), (4) SFP+ 1/10GbE ports, (1) port expansion module slot.
Operational conditions
Operating temperature (T-T) -5 - 45 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 5 - 95%
Storage relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 460 mm
Depth 440 mm
Height 43.6 mm
Weight 9.2 kg
