£6,305.99

Stock Available: 0
  • Double-conversion (Online)
  • 5 kVA 4500 W
  • Waveform: Sine
  • 4 AC outlet(s)
  • Sealed Lead Acid (VRLA)
  • Rackmount Black

Does your IT workload require high availability power protection? HPE Online Double Conversion Rackmount Uninterruptible Power System enables high system availability by eliminating transfer time to battery power for all connected IT equipment. HPE Enhanced Battery Management technology improves battery service life by up to 50% [1] while monitoring battery health and providing advanced notice when replacement is required. Scale system runtime from minutes to hours by adding up to four Extended Runtime Modules. HPE Online Double Conversion UPS includes a 1GbE Network Management Module that provides access to the UPS and its embedded web-based user interface, allowing you to monitor and manage individual UPS systems. With Eaton Intelligent Power Manager software, users can centralize remote monitoring and management of multiple HPE UPS systems and seamlessly integrate them into virtualization platforms, such as HPE SimpliVity, to manage virtual machines and extend battery runtime.

What is new supporting point:
Brings Online Double-Conversion technology to the Hewlett Packard Enterprise single-phase UPS portfolio.
Supports the HPE 1GbE Network Management Module as a standard feature.
Provides virtualization-ready support for HPE SimpliVity when using the Eaton Intelligent Power Manager software (free download).
Adds a UPS model for North America and Japan (NA/JPN) specifically targeting backup power for larger network switches.
Adds an R6000 international (INTL) model that provides 20% [2] more power than current R5000 INTL model.
Supports greater flexibility by adding hardwired power input for 30A/32A models (R8000).

Features
Efficiency 92.8%
Number of input phases 1
Output voltage regulation -10 - 6%
Output operation voltage (max) 180 V
Input frequency 40/60 Hz
Input operation voltage (max) 208 V
Input operation voltage (min) 200 V
Waveform Sine
Output power 4500 W
Output power capacity 5 kVA
UPS topology Double-conversion (Online)
Ports & interfaces
RS-232 ports 1
Serial interface type RS-232
Serial interface Yes
USB port Yes
AC outlets quantity 4 AC outlet(s)
Power plug NEMA L6-30P
AC outlet types NEMA L6-20R, NEMA L6-30R
Battery
Battery recharge time 24 h
Battery technology Sealed Lead Acid (VRLA)
Design
Rack capacity 3U
Product colour Black
Form factor Rackmount
Operational conditions
Storage relative humidity (H-H) 5 - 90%
Operating relative humidity (H-H) 0 - 95%
Storage temperature (T-T) -15 - 40 °C
Operating temperature (T-T) 0 - 40 °C
Weight & dimensions
Weight 49.2 kg
Height 129.5 mm
Depth 4394 mm
Width 1295 mm
Logistics data
Harmonized System (HS) code 85078000
