£1,140.99

Stock Available: 0
  • Ethernet WAN DSL WAN 3G/4G USB modem compatibility
  • IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3
  • Gigabit Ethernet
  • ADSL ADSL2 ADSL2+
  • DHCP client DHCP server
  • 3DES, 128-bit WEP, 192-bit AES, 256-bit AES, DES, MD5, SHA-1

The HPE FlexNetwork MSR1000 Router Series delivers high-performance, small branch routing up to 500 Kpps in a cost-optimized modular form factor. Featuring integrated routing, switching, security, and SIP with no additional licensing, you can boost your service delivery while simplifying the management of your corporate WAN. With Comware v7 and a convenient modular design, the MSR1000 brings enhanced performance and advanced services, as well as a choice of connectivity options to provide flexible, open standards and lasting investment protection with lower CAPEX and OPEX for small-sized branches.

Features

Reduces Complexity and Simplifies Your Network
- The HPE FlexNetwork MSR1000 Router Series simplifies your network through integrated routing, switching, security, and voice, and combines the flexibility of modular upgrades to deliver high-performance small branch routing.
- Makes administration easier with HPE Intelligent Management Center (IMC) Software.
- Reduces management complexity with zero-touch deployment (ZTP) and Dynamic VPN.

Enhances Time to Service and Branch Performance
- The HPE FlexNetwork MSR1000 Router Series offers high performance routing with up to 500 Kpps forwarding and 170 Mbps of IPSec encryption throughput to meet bandwidth requirements of branch traffic.
- Supports branch requirements with a comprehensive feature set to improve service delivery.
- Eases the transition to the cloud with integrated security.

Increases Your Return on Your Investment
- The HPE FlexNetwork MSR1000 Router Series is a compact modular platform with a wide range of connectivity options that enables the right design for your needs.
- Reduces your TCO through open standards, power and space savings, and energy-efficient hardware.
- Deploy advanced features with no additional licensing.

Boosts Agility and Resiliency
- The HPE FlexNetwork MSR1000 Router Series provides branch service and business continuity with 4G/LTE and 3G WAN.
- Gives you an open standards approach to your network infrastructure.
- With advanced hardware architecture, you get reliable, high-performance functionality with multi-core processors.

WAN connection
3G/4G USB modem compatibility Yes
SIM card slot No
DSL WAN Yes
Ethernet WAN Yes
Network
Throughput 0.5 Gbit/s
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet interface type Gigabit Ethernet
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3
DSL features
SHDSL Yes
ADSL2+ Yes
ADSL2 Yes
ADSL Yes
Management features
Quality of Service (QoS) support Yes
Web-based management No
Ports & interfaces
USB version 2.0
USB ports quantity 1
Ethernet LAN (RJ-45) ports 8
Protocols
IPv4 & IPv6 features IPv4/IPv6 access-control list (ACL)
Routing protocols BGP, BGP4, MPLS, OSPF, OSPFv3, RIP, RIP-1, RIP-2
DHCP client Yes
DHCP server Yes
Security
Access Control List (ACL) Yes
Firewall Yes
Security algorithms 3DES, 128-bit WEP, 192-bit AES, 256-bit AES, DES, MD5, SHA-1
Features
Heat dissipation 65 BTU/h
Internal memory type DDR3
Internal memory 512 MB
Flash memory 256 MB
Processor frequency 667 MHz
Built-in processor Yes
Design
Product colour Grey
Power
AC input frequency 50 - 60 Hz
AC input voltage 100 - 240 V
Power consumption (typical) 30 W
Operational conditions
Storage relative humidity (H-H) 5 - 95%
Operating relative humidity (H-H) 5 - 95%
Storage temperature (T-T) -40 - 70 °C
Operating temperature (T-T) 0 - 45 °C
Weight & dimensions
Weight 3.15 kg
Height 44.2 mm
Depth 300 mm
Width 360 mm
