• Managed L3
• Quality of Service (QoS) support
• Basic switching RJ-45 Ethernet ports quantity: 48 Console port: RJ-45
• 10G support 10GBASE-T
• MAC address table: 98304 entries Switching capacity: 2500 Gbit/s
• Access Control List (ACL)
• 1U Rack mounting Stackable
• AC Power supply included

The HPE Aruba Networking CX 8320 Switch Series provides industry‑leading line rate 1/10GbE (SFP/SFP+ and 10GBASE‑T) and 40GbE connectivity in a compact 1U form factor. It provides up to 2.5 Tbps of switching capacity with redundant power and fans combined with HPE Aruba Networking Virtual Switching Extension (VSX) for a high availability solution ideal for enterprise campus and data center deployments. The CX 8320 also serves as a top of rack (ToR) switch for data centers needing 10GbE connectivity to servers and 40GbE to the spine. The CX 8320 is based on HPE Aruba Networking CX Switch Operating System (AOS-CX), a modern, database‑driven operating system that automates and simplifies many critical and complex network tasks. A built‑in time series database enables customers and developers to utilize software scripts for historical troubleshooting, as well as analysis of past trends. This helps predict and avoid future problems due to scale, security, and performance bottlenecks.

What is new supporting point:
High-performance campus core and aggregation switch with 2.5 Tbps switching capacity.
HPE Aruba Networking CX Switch Operating System (AOS-CX) automates using REST APIs and Python scripts.
Monitor and troubleshoot with HPE Aruba Networking Network Analytics Engine (NAE).
Advanced Layer 2/3 feature set includes BGP, OSPF, VRF and IPv6.
High availability, virtualization and simplicity with HPE Aruba Networking Virtual Switching Extension (VSX).
Compact 1U switches with 10 GbE (SFP/SFP+ or 10 GBASE-T) and 40 GbE connectivity.
