Overview
The HPE Aruba Networking CX 8100 Switch Series serves the needs of modern campus core and aggregation as well as dynamic top-of-rack (ToR) data center environments, offering a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud, and IoT. The CX 8100 switches are based on HPE Aruba Networking CX Switch Operating System (AOS-CX) that automates and simplifies critical network tasks, offers programmability with REST APIs and Python scripts, delivers enhanced fault tolerance and zero-service disruption during planned or unplanned control-plane events. Real-time, network-wide visibility and analytics are available in every switch. The series includes industry-leading line rate ports with 1/10GbE (SFP/SFP+) and 40/100GbE (QSFP+/QSFP28) connectivity in a compact 1U form factor. 4 x 10 Gbps and 4 x 25 Gbps break out from 40/100G. These switches are great for customers needing 1/10GbE with mix of fiber and copper ports.
What is new supporting point:
High availability with industry-leading HPE Aruba Networking Virtual Switching Extension (VSX) redundancy and redundant power supplies and fans
HPE Aruba Networking CX Switch Operating System (AOS-CX) automation and programmability using built-in REST APIs and Python scripts
Intelligent monitoring and visibility delivered by the HPE Aruba Networking CX Networks Analytics Engine (NAE)
High performance 1.76 Tbps of bi-directional switching and 1,309 Mpps of forwarding designed for aggregation in the campus or top-of-rack (ToR) in data center environments
Four different base models, each sold in bundles that support two airflow modes (front-to-back, and back-to-front) with advanced Layer 2/3 feature set that includes BGP, OSPF, VRF, VXLAN, EVPN, IPv6
Specifications
Data transmission
| Switching capacity | 1280 Gbit/s |
|---|
Performance
| Built-in processor | Yes |
|---|---|
| Processor frequency | 1800 MHz |
| Internal memory | 16000 MB |
Show all 14 specificationsShow fewer specifications
Power
| AC input voltage | 200 - 240 V |
|---|---|
| Power consumption (max) | 375 W |
| Power consumption note | Maximum: 375W Idle: 120W |
| Power supply note | Bundles include the 2 power supplies (2 x JL712A) |
Other features
| Fan | 3 field-replaceable and hot-swappable fans |
|---|---|
| Performance management | RJ-45 serial and USB-C console RJ-45 Ethernet port USB Type-A |
| Memory and processor | CPU: Quad Core Arm Cortex™ A72 @ 1.8 GHz Memory and flash: 16 GB RAM, 32 GB Flash/storage Packet buffer: 32 MB |
| I/O ports | 24 ports of 1/10GbE (SFP/SFP+) 4 ports of 40/100GbE (QSFP+/QSFP28) |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Heat dissipation | 1275 BTU/h |
