HPE Aruba Networking AP-567EX (RW) Dual Radio 2x2 Wi-Fi 6 Internal Directional HazLoc Access Point
HPE Aruba Networking AP-567EX (RW) Dual Radio 2x2 Wi-Fi 6 Internal Directional HazLoc Access Point
HPE Aruba Networking AP-567EX (RW) Dual Radio 2x2 Wi-Fi 6 Internal Directional HazLoc Access Point
HPE Aruba Networking AP-567EX (RW) Dual Radio 2x2 Wi-Fi 6 Internal Directional HazLoc Access Point

HPE Aruba Networking AP-567EX (RW) Dual Radio 2x2 Wi-Fi 6 Internal Directional HazLoc Access Point

Hewlett Packard Enterprise
£1,582.99
Stock Available: 0
  • Class 1 Division 2 and ATEX Zone 2 certified outdoor Wi-Fi 6 access points that provide up to 1.49 Gbps maximum aggregate data rate
  • Purpose built for hazardous locations and to survive in one of the harshest outdoor environments and extreme temperatures (-40˚C to +65˚C)
  • Internet of Things (IoT)-ready with a built-in1 Bluetooth 5 and 802.15.4 radio that supports Zigbee
  • Client and RF optimization to match clients with the best available access point and reduce coverage gaps
  • Dynamic Segmentation and policy enforcement firewalls (PEF) that automatically enforces consistent policies across all networks, keeping users and devices secure

HPE Aruba Networking 560EX Series Hazardous Location Access Points provide cost-effective Wi-Fi 6 connectivity for outdoor hazardous locations like oil fields and rigs, mining facilities, and environments with explosive atmospheres and vapors that need Class 1 Division 2 or ATEX Zone 2 solutions. With Wi-Fi 6 capabilities, Bluetooth 5 and 802.15.4/Zigbee radios, and maximum aggregate data rate of 1.49 Gbps, the 560EX Series delivers the speed and reliability needed to bring Wi-Fi to hazardous locations. These Wi-Fi 6 outdoor APs are purpose-built for hazardous locations and can be quickly deployed using Zero Touch Provisioning. HPE Aruba Networking Central provides a single pane of glass for overseeing wired and wireless LANs, WANs, and VPNs. AI‑powered analytics, end‑to‑end orchestration and automation, and advanced security features are built natively into the solution. The 560EX Series includes a limited lifetime warranty.

What is new supporting point:
Internet of Things (IoT)-ready with a built-in [1] Bluetooth 5 and 802.15.4 radio that supports Zigbee.
Client and RF optimization to match clients with the best available access point and reduce coverage gaps.
Dynamic Segmentation and policy enforcement firewalls (PEF) that automatically enforces consistent policies across all networks, keeping users and devices secure.
Purpose built for hazardous locations and to survive in one of the harshest outdoor environments and extreme temperatures (-40˚C to +65˚C).
Class 1 Division 2 and ATEX Zone 2 certified outdoor Wi-Fi 6 access points that provide up to 1.49 Gbps maximum aggregate data rate.

Features
Spread spectrum method OFDMA
MIMO type Multi User MIMO
MIMO Yes
Auto MDI/MDI-X Yes
Bluetooth version 5.0
Bluetooth Yes
Networking standards IEEE 802.15.4
Ethernet LAN data rates 10,100,1000 Mbit/s
Maximum data transfer rate (5 GHz) 1200 Mbit/s
Maximum data transfer rate (2.4 GHz) 575 Mbit/s
Maximum data transfer rate 1774 Mbit/s
5 GHz Yes
6 GHz No
2.4 GHz Yes
Security
Security algorithms WPA2, WPA3
Ports & interfaces
USB connector type USB Type-C
Ethernet LAN (RJ-45) ports 1
Power
DC voltage range 48 V
Power over Ethernet (PoE) Yes
Design
Product colour White
Placement Pole, Wall
Antenna
Polarization Dual polarization
Antenna gain level (max) 7 dBi
Antenna features Integrated antenna
Antenna direction type Directional
Antenna type Internal
General
Product family Aruba Networking
Certificates
Certification None
Compliance certificates Low Voltage Directive (LVD)
Weight & dimensions
Weight 1.09 kg
Height 121 mm
Depth 160 mm
Width 160 mm
